DS1858
Dual Temperature-Controlled Resistors with
Three Monitors
SDA
SCL
t HD:STA
t LOW
t HIGH
t R t F
t BUF
t HD:DAT
t SU:DAT REPEATED
START
t SU:STA
t HD:STA
t SU:STO
t SP
STOP START
Figure 6. 2-Wire AC Characteristics
