AT6000(LV) Series
22
DC Characteristics – 5V Operation
Symbol Parameter Conditions Min Max Units
V
IH
High-level Input Voltage Commercial
CMOS 70% V
CC
V
CC
V
TTL 2.0 V
CC
V
V
IL
Low-level Input Voltage Commercial
CMOS 0 30% V
CC
V
TTL 0 0.8 V
V
OH
High-level Output Voltage Commercial
I
OH
= -4 mA, V
CC
min 3.9 V
I
OH
= -16 mA, V
CC
min 3.0 V
V
OL
Low-level Output Voltage Commercial
I
OL
= 4 mA, V
CC
min 0.4 V
I
OL
= 16 mA, V
CC
min 0.5 V
I
OZH
High-level Tristate
V
O
= V
CC
(max) 10 µA
Output Leakage Current
I
OZL
High-level Tristate Without Pull-up, V
O
= V
SS
-10 µA
Output Leakage Current With Pull-up, V
O
= V
SS
-500 µA
I
IH
High-level Input Current V
IN
= V
CC
(max) 10 µA
I
IL
Low-level Input Current
Without Pull-up, V
IN
= V
SS
-10 µA
With Pull-up, V
IN
= V
SS
-500 µA
I
CC
Power Consumption Without Internal Oscillator (Standby) 500 µA
C
IN
Input Capacitance All Pins 10 pF
