MAX5048
7.6A, 12ns, SOT23 MOSFET Driver
2
_______________________________________________________________________________________
ABSOLUTE MAXIMUM RATINGS
ELECTRICAL CHARACTERISTICS
(V+ = +12V, T
A
= -40°C to +125°C, unless otherwise noted. Typical values are at T
A
= +25°C.) (Note 2)
Stresses beyond those listed under “Absolute Maximum Ratings” may cause permanent damage to the device. These are stress ratings only, and functional
operation of the device at these or any other conditions beyond those indicated in the operational sections of the specifications is not implied. Exposure to
absolute maximum rating conditions for extended periods may affect device reliability.
Voltages Referenced to GND
V+ ...........................................................................-0.3V to +13V
IN+, IN-...................................................................-0.3V to +14V
N_OUT, P_OUT ............................................-0.3V to (V+ + 0.3V)
N_OUT Continuous Output Current (Note 1) ....................390mA
P_OUT Continuous Output Current (Note 1).....................100mA
Continuous Power Dissipation (T
A
= +70°C)
6-Pin SOT23 (derate 8.7mW/°C above +70°C)............696mW
Operating Temperature Range .........................-40°C to +125°C
Storage Temperature Range .............................-65°C to +150°C
Junction Temperature ......................................................+150°C
Lead Temperature (soldering, 10s) .................................+300°C
Note 1: Continuous output current is limited by the power dissipation of the SOT23 package.
PARAMETER
SYMBOL
CONDITIONS
MIN
TYP
MAX
UNITS
POWER SUPPLY
V+ Operating Range
V+
4.0
12.6
V
V+ Undervoltage Lockout
UVLO
V+ rising
3.25
3.6
4.00
V
V+ Undervoltage Lockout
Hysteresis
400
mV
V+ Undervoltage Lockout to
Output Delay Time
V+ rising
300
ns
V+ Supply Current
I+
IN+ = IN- = V+
0.95
1.5
mA
N-CHANNEL OUTPUT
T
A
= +25
°C
0.23
0.26
V+ = +10V,
I
N-OUT
= -100mA
T
A
= +125
°C
0.38
0.43
T
A
= +25
°C
0.24
0.28
Driver Output Resistance—
Pulling Down
R
ON-N
V+ = +4.5V,
I
N-OUT
= -100mA
T
A
= +125
°C
0.40
0.47
Ω
Power-Off Pulldown Resistance
V+ = 0 or floating, I
N-OUT
= -10mA
3.3
10
Ω
Power-Off Pulldown Clamp
Voltage
V+ = 0 or floating, I
N-OUT
= -10mA
0.85
1.0
V
Output Leakage Current
I
LK-N
N_OUT = V+
6.85
20
µA
Peak Output Current (Sinking)
I
PK-N
C
L
= 10,000pF
7.6
A
P-CHANNEL OUTPUT
T
A
= +25
°C
2.00
3.00
V+ = +10V,
I
P-OUT
= 50mA
T
A
= +125
°C
2.85
4.30
T
A
= +25
°C
2.20
3.30
Driver Output Resistance—
Pulling Up
R
ON-P
V+ = +4.5V,
I
P-OUT
= 50mA
T
A
= +125
°C
3.10
4.70
Ω
Output Leakage Current
I
LK-P
P_OUT = 0
0.001
10
µA
Peak Output Current (Sourcing)
I
PK-P
C
L
= 10,000pF
1.3
A
LOGIC INPUT
MAX5048A
0.67 x V+
Logic 1 Input Voltage
V
IH
MAX5048B
2.4
V
MAX5048A
0.33 x V+
Logic 0 Input Voltage
V
IL
MAX5048B
0.8
V
