MAX9867
Ultra-Low Power Stereo Audio Codec
_______________________________________________________________________________________ 3
PARAMETER SYMBOL CONDITIONS MIN TYP MAX UNITS
Shutdown to Full Operation Excludes PLL lock time 10 ms
Soft-Start/-Stop Time 10 ms
DAC (Note 4)
Master or slave
mode
90
Dynamic Range (Note 5) DR
f S = 48kHz, AV VOL =
+0dB, T A = +25°C
Slave mode 84
dB
Differential mode 1
Full-Scale Output V OLL /V OLR = 0 x 09 Capacitorless and
single-ended modes
0.56
V RMS
Gain Error
DC accuracy, measured with respect to
full-scale output
1 5 %
f S = 8kHz 1.2
Voice Path Phase Delay P DLY
f = 1kH z, 0d BFS , H P
fi l ter d i sab l ed , d i g i tal
i np ut to anal og outp ut
f S = 16kHz 0.59
ms
Total Harmonic Distortion THD
MCLK = 12.288MHz, f S = 48kHz, 0dBFS,
measured at headphone outputs
-80 dB
DAC Attenuation Range AV DAC DACA = 0xF to 0x0 -15 0 dB
DAC Gain Adjust AV GAIN DACG = 00 to 11 0 +18 dB
V AVDD = V PVDD = 1.65V to 1.95V 60 78
f = 217Hz, V RIPPLE = 100mV P-P ,
AV VOL = 0dB
78
f = 1kHz, V RIPPLE = 100mV P-P ,
AV VOL = 0dB
75
Power-Supply Rejection Ratio PSRR
f = 10kHz, V RIPPLE = 100mV P-P ,
AV VOL = 0dB
62
dB
DAC VOICE MODE DIGITAL IIR LOWPASS FILTER
With respect to f S within ripple; f S = 8kHz to
48kHz
0.448 x
f S
Passband Cutoff f PLP
-3dB cutoff
0.451 x
f
S
Hz
Passband Ripple f < f PLP ±0.1 dB
Stopband Cutoff f SLP With respect to f S ; f S = 8kHz to 48kHz
0.476 x
f S
Hz
Stopband Attenuation f > f SLP , f = 20Hz to 20kHz 75 dB
ELECTRICAL CHARACTERISTICS (continued)
(V AVDD = V PVDD = V DVDD = V DVDDIO = +1.8V, R L = ∞, headphone load (R L ) connected between _OUTP and _OUTN in differential
mode, C REF = 2.2μF, C MICBIAS = C PREG = C REG = 1μF, AV PRE = +20dB, AV PGAM = 0dB, AV DAC = 0dB, AV LINE = +20dB, AV VOL =
0dB, MCLK = 13MHz, T A = T MIN to T MAX , unless otherwise noted. Typical values are at T A = +25°C.) (Note 2)
