General Description

The MAX13330/MAX13331 stereo headphone amplifiers
are designed for automotive applications requiring out-
put short-circuit and ESD protection to battery/ground
with diagnostics. These devices use Maxim’s unique,
patented

DirectDrive

®

architecture to produce a

ground-referenced output from a single supply, elimi-
nating the need for large DC-blocking capacitors, sav-
ing board space and component height. The gain of the
amplifier is set internally (-1.5V/V) on the MAX13330 or
adjusted externally with resistors on the MAX13331.

The MAX13330/MAX13331 deliver 120mW per channel
into a 16Ω load or 135mW into a 32Ω load and have a
low 0.01% THD+N. Low output impedance and the effi-
cient integrated charge pump allows the device to drive
loads as low as 8Ω, enabling the use of small loud-
speakers. An 80dB at 217Hz PSRR allows these
devices to operate from noisy digital supplies without
an additional linear regulator. These devices include
±15kV Human Body Model ESD protection and short-
circuit protection up to +45V at the headphone outputs.
Comprehensive click-and-pop circuitry suppresses
audible clicks and pops on startup and shutdown. A
low-power shutdown mode reduces the supply current
to 3µA (typ).

The MAX13330/MAX13331 are specified from -40°C to
+105°C AEC-Q100 Level 2 automotive temperature
range and are available in a 16-pin QSOP package.

Applications

Automotive Entertainment Systems

Automotive Rear Seat Entertainment Systems

Features

4V to 5.5V Single-Supply Operation
2MHz Charge Pump Prevents AM Radio

Interference

Ground-Referenced Outputs Eliminate Bulky DC-

Blocking Capacitors

Short-to-Ground and Battery (V

BAT

up to +45V)

Output Protection, Load Dump Protection

Short-Circuit Diagnostic Output
Adjustable Gain (MAX13331) or Fixed -1.5V/V Gain

(MAX13330)

135mW per Channel into 32Ω at 1% THD+N
Low 0.01% THD+N
Integrated Click-and-Pop Suppression
High PSRR Eliminates LDO
No Degradation of Low-Frequency Response Due

to Output Capacitors

±15kV Human Body Model ESD Protection for

Output Pins

MAX13330/MAX13331

Automotive DirectDrive Headphone Amplifiers

with Output Protection and Diagnostics

________________________________________________________________

Maxim Integrated Products

1

MAX13330
MAX13331

OUTR

V

SS

PGND

OUTL

13

14

15

16

4

3

2

1

SGND

DIAG

12

5

V

DD

INR

SGND

INL

QSOP

+

PGND

C1N

CPVSS

9

10

11

8

7

6

C1P

CPVDD

SHDN

Pin Configuration

CLICK-AND-POP

SUPPRESSION

OUTPUT PROTECTION & DIAGNOSTICS

RIGHT-CHANNEL

AUDIO IN

LEFT-CHANNEL

AUDIO IN

MAX13330

DIAGNOSTICS
OUTPUT

SHDN

Simplified Block Diagram

19-4341; Rev 0; 10/08

For pricing, delivery, and ordering information, please contact Maxim Direct at 1-888-629-4642,
or visit Maxim’s website at www.maxim-ic.com.

DirectDrive is a registered trademark of Maxim Integrated
Products, Inc.

U.S. Patent #7,061,327

Ordering Information

+

Denotes a lead-free/RoHS-compliant package.

T = Tape-and-reel.
/V denotes an automotive qualified part.
Typical Application Circuits appear at end of data sheet.

PART

GAIN

TEMP

RANGE

PIN-

PACKAGE

M A X1 3 3 3 0 GE E /V + T

-1.5V/V

- 40°C to + 105°C

16 QSOP

M A X1 3 3 3 1 GE E /V + T

E xter nal l y

Set

- 40°C to + 105°C

16 QSOP
