MAX9867
Ultra-Low Power Stereo Audio Codec
2 _______________________________________________________________________________________
ABSOLUTE MAXIMUM RATINGS
ELECTRICAL CHARACTERISTICS
(V
AVDD
= V
PVDD
= V
DVDD
= V
DVDDIO
= +1.8V, R
L
= ∞, headphone load (R
L
) connected between _OUTP and _OUTN in differential
mode, C
REF
= 2.2μF, C
MICBIAS
= C
PREG
= C
REG
= 1μF, AV
PRE
= +20dB, AV
PGAM
= 0dB, AV
DAC
= 0dB, AV
LINE
= +20dB, AV
VOL
=
0dB, MCLK = 13MHz, T
A
= T
MIN
to T
MAX
, unless otherwise noted. Typical values are at T
A
= +25°C.) (Note 2)
Stresses beyond those listed under “Absolute Maximum Ratings” may cause permanent damage to the device. These are stress ratings only, and functional
operation of the device at these or any other conditions beyond those indicated in the operational sections of the specifications is not implied. Exposure to
absolute maximum rating conditions for extended periods may affect device reliability.
(Voltages with respect to AGND.)
DVDD, AVDD, and PVDD .........................................-0.3V to +2V
DVDDIO.................................................................-0.3V to +3.6V
DGND and PGND..................................................-0.1V to +0.1V
PREG, REF, REG, MICBIAS ....................-0.3V to (AVDD + 0.3V)
MCLK, LRCLK, BCLK
SDOUT, SDIN .................................-0.3V to (DVDDIO + 0.3V)
SDA, SCL, IRQ ......................................................-0.3V to +3.6V
LOUTP, LOUTN, ROUTP,
ROUTN .................................(PGND - 0.3V) to (PVDD + 0.3V)
LINL, LINR, JACKSNS/AUX, MICLP/DIGMICDATA,
MICLN/DIGMICCLK, MICRP, MICRN..-0.3V to (AVDD + 0.3V)
Continuous Power Dissipation (T
A
= +70°C)
30-Bump WLP (derate 12.5mW/°C above +70°C) ....1000mW
32-Pin TQFN-EP (derate 34.5mW/°C above +70°C) .2759mW
Junction-to-Ambient Thermal Resistance ( θ
JA
) (Note 1)
30-Bump WLP .............................................................80°C/W
32-Pin TQFN-EP ..........................................................29°C/W
Operating Temp Range .......................................-40°C to +85°C
Storage Temp Range ........................................-65°C to +150°C
PARAMETER SYMBOL CONDITIONS MIN TYP MAX UNITS
PVDD, DVDD, AVDD 1.65 1.8 1.95
Supply Voltage Range
DVDDIO 1.65 1.8 3.6
V
Analog (AVDD +
PVDD)
4.65 7
Full-duplex 8kHz
mono (voice mode)
(Note 3)
Digital (DVDD +
DVDDIO)
0.96 1.5
Analog (AVDD +
PVDD)
3.28 5
DAC playback 48kHz
stereo (audio mode)
(Note 3)
Digital (DVDD +
DVDDIO)
1.40 2
Analog (AVDD +
PVDD)
8.0 12
Full-duplex 48kHz
stereo (audio mode)
(Note 3)
Digital (DVDD +
DVDDIO)
2.0 3
Analog (AVDD +
PVDD)
3.8 6
Total Supply Current I VDD
Stereo line-in only
Digital (DVDD +
DVDDIO)
0.004 0.05
mA
Analog (AVDD +
PVDD)
1 5
Shutdown Supply Current T A = +25°C
Digital (DVDD +
DVDDIO)
1 5
μA
Note 1: Package thermal resistances were obtained using the method described in JEDEC specification JESD51-7, using a four-
layer board. For detailed information on package thermal considerations, refer to www.maxim-ic.com/thermal-tutorial .
