Typical Performance Characteristics
(Continued)
(Through Mux)
SINAD vs Input Frequency
(Through Mux)
SNR vs Input Frequency
(Through Mux)
THD vs Input Frequency
Impedance
SNR and THD vs Source
Reference Voltage
SNR and THD vs
TL H 11490 – 28
Timing Diagrams
TL H 11490 – 9
FIGURE 1 Interrupt Interface Timing
(MODE e 1 OE e 1)
7
