MAX4399
Audio/Video Switch for Three SCART
Connectors
_______________________________________________________________________________________ 5
ELECTRICAL CHARACTERISTICS (continued)
(V V12 = 12V, V V_VID = 5V, V V_DIG = 5V, 0.47µF X5R capacitor in parallel with a 10µF aluminum electrolytic capacitor from V_AUD to
G_AUD, no load, T A = 0°C to +70°C, unless otherwise noted. Typical values are at T A = +25°C.) (Note 1)
PARAMETER SYMBOL CONDITIONS MIN TYP MAX UNITS
Minimum Receive SCL/SDA Rise
Time (Note 3)
t R
20 +
0.1C B
ns
Maximum Receive SCL/SDA Fall
Time (Note 3)
t F 300 ns
Minimum Receive SCL/SDA Fall
Time (Note 3)
t F
20 +
0.1C B
ns
Setup Time for Stop Condition t SU,STO 0.6 µs
Bus Free Time Between a Stop
and Start
t BUF 1.3 µs
OTHER DIGITAL PINS
DEV_ADDR Low Level 0.8 V
DEV_ADDR High Level 2.6 V
INTERRUPT_OUT Low Voltage INTERRUPT_OUT sinking 1mA 0.15 0.4 V
INTERRUPT_OUT High Leakage
Current
V INTERRUPT_OUT = 5V 1 10 µA
SLOW SWITCHING
Input Low Level 0 2 V
Input Medium Level 4.5 7.0 V
Input High Level 9.5 12.0 V
Input Current 50 100 µA
Output Low Level R LOAD = 10k Ω to ground 0 1.5 V
Output Medium Level (External
16/9)
R LOAD = 10k Ω to ground 5.0 6.5 V
Output High Level (External 4/3) R LOAD = 10k Ω to ground 10 12 V
FAST SWITCHING
Input Low Level 0 0.4 V
Input High Level 1 3 V
Input Current 1 10 µA
Output Low Level I SINK = 0.5mA 0 0.01 0.2 V
Output High Level V_VID - V OH , I SOURCE = 20mA 0.75 2 V
Fast-Switching Output to RGB
Skew
Difference in propagation delays of fast-
switching signal and RGB signals;
measured from 50% input transition to 50%
output transition
30 ns
Fast-Switching Output Rise Time R LOAD = 150 Ω to ground 30 ns
Fast-Switching Output Fall Time R LOAD = 150 Ω to ground 30 ns
Note 1: All devices are 100% tested at T A = +25°C. All temperature limits are guaranteed by design.
Note 2: Parameter guaranteed by design.
Note 3: C
B = total capacitance of one bus line in pF. Tested with C B = 400pF.
