MAX4399
Audio/Video Switch for Three SCART
Connectors
______________________________________________________________________________________ 27
Table 14. 09h: VCR Video Output Control
BIT
DESCRIPTION
7 6 5 4 3 2 1 0
COMMENTS
— — — — — — 0 0
Low (<2V) internal source (power-on
default)
— — — — — — 0 1
Medium (4.5V to 7V). External SCART
source with 16:9 aspect ratio.
— — — — — — 1 0 High impedance
Set VCR Slow Switching
— — — — — — 1 1
High (>9.5V). External SCART source with
4:3 aspect ratio.
— — — — — 0 — —
Normal operation. Pulldown on
TV_R/C_OUT is off (power-on default)
VCR_R/C_OUT Ground
— — — — — 1 — —
Ground. Pulldown on TV_R/C_OUT is on.
The output amplifier driving
VCR_R/C_OUT turns off.
Table 15. Register 0Ah: AUX Video Input Control
BIT
DESCRIPTION
7 6 5 4 3 2 1 0
COMMENTS
— — — — — — — — AUX_Y/CVBS_OUT AUX_R/C_OUT
— — — — — 0 0 0 ENC_Y/CVBS_IN ENC_R/C_IN
— — — — — 0 0 1 ENC_Y_IN ENC_C_IN
— — — — — 0 1 0 VCR_Y/CVBS_IN VCR_R/C_IN
— — — — — 0 1 1 AUX_Y/CVBS_IN AUX_R/C_IN
— — — — — 1 0 0 TV_Y/CVBS_IN TV_R/C_IN
— — — — — 1 0 1 Mute Mute
— — — — — 1 1 0 Mute Mute
Input Sources for AUX Video
— — — — — 1 1 1
Mute (power-on
default) Mute (power-on
default)
0 — — — — — — —
DC restore clamp active at input (power-
on default)
AUX_R/C_IN Clamp/Bias
1 — — — — — — — Chroma bias applied at input
Table 16. Register 0Bh: AUX Video Output Control
BIT
DESCRIPTION
7 6 5 4 3 2 1 0
COMMENTS
— — — — — — 0 0
Low (<2V). Internal source (power-on
default).
— — — — — — 0 1
Medium (4.5V to 7V). External SCART
source with 16:9 aspect ratio.
— — — — — — 1 0 High impedance
Set AUX Slow Switching
— — — — — — 1 1
High (>9.5V). External SCART source
with 4:3 aspect ratio.
— — — — — 0 — —
Normal operation. Pulldown on
TV_R/C_OUT is off (power-on default).
AUX_R/C_OUT Ground
— — — — — 1 — —
Ground. Pulldown on TV_R/C_OUT is
on. The output amplifier driving
AUX_R/C_OUT turns off.
