�� Maxim Integrated Products 16

MAX13256

36V H-Bridge Transformer

Driver for Isolated Supplies

Ordering Information

Package Information

For the latest package outline information and land patterns
(footprints), go to

www.maxim-ic.com/packages

. Note that a

“+”, “#”, or “-” in the package code indicates RoHS status only.
Package drawings may show a different suffix character, but
the drawing pertains to the package regardless of RoHS status.

+Denotes a lead(Pb)-free/RoHS-compliant package.
*EP = Exposed Pad

Chip Information

PROCESS: BiCMOS

PACKAGE

TYPE

PACKAGE

CODE

OUTLINE

NO.

LAND

PATTERN NO.

10 TDFN-EP

T1033+1

21-0137

90-0003

PART

TEMP RANGE

PIN-PACKAGE

MAX13256ATB+

-40NC to +125NC

10 TDFN-EP*
