MAX7311
2-Wire-Interfaced 16-Bit I/O Port Expander
with Interrupt
______________________________________________________________________________________ 13
AD2 AD1 AD0 A6 A5 A4 A3 A2 A1 A0 ADDRESS (HEX)
SCL SCL GND 1 0 1 0 0 0 0 0xA0
SCL SCL V + 1 0 1 0 0 0 1 0xA2
SCL SDA GND 1 0 1 0 0 1 0 0xA4
SCL SDA V + 1 0 1 0 0 1 1 0xA6
SDA SCL GND 1 0 1 0 1 0 0 0xA8
SDA SCL V + 1 0 1 0 1 0 1 0xAA
SDA SDA GND 1 0 1 0 1 1 0 0xAC
SDA SDA V + 1 0 1 0 1 1 1 0xAE
SCL SCL SCL 1 0 1 1 0 0 0 0xB0
SCL SCL SDA 1 0 1 1 0 0 1 0xB2
SCL SDA SCL 1 0 1 1 0 1 0 0xB4
SCL SDA SDA 1 0 1 1 0 1 1 0xB6
SDA SCL SCL 1 0 1 1 1 0 0 0xB8
SDA SCL SDA 1 0 1 1 1 0 1 0xBA
SDA SDA SCL 1 0 1 1 1 1 0 0xBC
SDA SDA SDA 1 0 1 1 1 1 1 0xBE
SCL GND GND 1 1 0 0 0 0 0 0xC0
SCL GND V + 1 1 0 0 0 0 1 0xC2
SCL V + GND 1 1 0 0 0 1 0 0xC4
SCL V + V + 1 1 0 0 0 1 1 0xC6
SDA GND GND 1 1 0 0 1 0 0 0xC8
SDA GND V + 1 1 0 0 1 0 1 0xCA
SDA V + GND 1 1 0 0 1 1 0 0xCC
SDA V + V + 1 1 0 0 1 1 1 0xCE
SCL GND SCL 1 1 0 1 0 0 0 0xD0
SCL GND SDA 1 1 0 1 0 0 1 0xD2
SCL V + SCL 1 1 0 1 0 1 0 0xD4
SCL V + SDA 1 1 0 1 0 1 1 0xD6
SDA GND SCL 1 1 0 1 1 0 0 0xD8
SDA GND SDA 1 1 0 1 1 0 1 0xDA
SDA V + SCL 1 1 0 1 1 1 0 0xDC
SDA V + SDA 1 1 0 1 1 1 1 0xDE
Table 7. MAX7311 Address Map (continued)
Chip Information
TRANSISTOR COUNT: 12,994
PROCESS: BiCMOS
