______________________________________________________________________________________ 21

MAX17127

Six-String WLED Driver with Integrated

Step-Up Converter

Simplified Operating Circuit (Direct-PWM Mode)

Package Information

For the latest package outline information and land patterns,
go to

www.maxim-ic.com/packages

. Note that a “+”, “#”, or

“-” in the package code indicates RoHS status only. Package
drawings may show a different suffix character, but the drawing
pertains to the package regardless of RoHS status.

Chip Information

PROCESS: BiCMOS

V

IN

EP

SW

V

DDIO

ISET

PGND

OVP

COMP

AGND

FB1

FB3

FB4

FB5

FB6

FSLCT

EN

PWM

FB2

R_FPWM

FPO

3.3V

I.C.

MAX17127

PACKAGE TYPE

PACKAGE CODE

DOCUMENT NO.

20 TQFN

T2044+3

21-0139
