18 _____________________________________________________________________________________

MAX17127

Six-String WLED Driver with Integrated

Step-Up Converter

Calculate the ripple current at that operating point and
the peak current required for the inductor:

(

)

IN(MIN)

OUT(MAX)

IN(MIN)

RIPPLE

OUT(MAX)

SW

RIPPLE

PEAK

IN(DC,MAX)

V

V

V

I

L V

f

I

I

I

2

Ч

=

Ч

Ч

=

+

When DCM operating mode is chosen to minimize the
inductor value, the calculations are different from those
above in CCM mode. The maximum inductor value for
DCM mode is calculated with the following equation:

IN(MIN)

DCM(MAX)

OUT(MAX)

DIODE

2

IN(MIN)

SW(MAX)

OUT(MAX)

OUT(MAX)

V

L

1

V

V

V

2 f

V

I

= −

+

× η

Ч

Ч

Ч

Ч

The peak inductor current in DCM is calculated with the
following equation:

(

)

(

)

OUT(MAX)

OUT(MAX)

OUT(MAX)

DIODE

IN(MIN)

PEAK

SW(MIN)

OUT(MAX)

DIODE

I

2 V

V

V

V

I

L f

V

V

Ч Ч

Ч

+

=

Ч

Ч ηЧ

+

The inductor’s saturation current rating should exceed
I

PEAK,

and the inductor’s DC current rating should

exceed I

IN(DC,MAX)

. For good efficiency, choose an

inductor with less than 0.1I series resistance.
Considering the circuit with six 10-LED strings and
20mA LED full-scale current, the maximum load current
(I

OUT(MAX)

) is 120mA with a 32V output and a minimal

input voltage of 7V.
Choosing a CCM operating mode with LIR = 0.7 at 1MHz
and estimating efficiency of 85% at this operating point:

2

7V

32V 7V

0.85

L

12.1 H

32V

120mA 1MHz

0.7

 



=

=

µ

 



×

 



In CCM, the inductor has to be higher than L

CCM(MIN)

:

(

)

CCM(MIN)

32V 0.4V 2 7V 13.7m

L

5.5 H

2 25.5mV 0.9MHz

+

− Ч

Ч

=

=

µ

Ч

Ч

A 10FH inductor is chosen, which is higher than the mini-
mum L that guarantees stability in CCM.
The peak inductor current at minimum input voltage is
calculated as follows:

(

)

PEAK

7V

32V 7V

120mA 32V

I

0.95A

7V 0.85

2 10 H 32V 0.9MHz

Ч

Ч

=

+

=

Ч

Ч µ Ч

Ч

Alternatively, choose a DCM operating mode by using
lower inductance and estimating efficiency of 85% at this
operating point. Since DCM has higher peak inductor
current at lower input, it causes current limit when the
parameters are not chosen properly. Considering the
case with six 10-LED strings and 20mA LED full-scale
current to prevent excessive switch current from causing
current limit:

DCM(MAX)

2

7V

L

1

32V 0.4V

(7V)

0.85

3.9 H

2 1.1MHz 32V 120mA

= −

+

Ч

Ч

=

µ

Ч

Ч

Ч

A 3.3FH inductor is chosen. The peak inductor current at
minimum input voltage is calculated as follows:

(

)

(

)

PEAK

120mA 2 32V

32V 0.4V 7V

I

1.40A

3.3 H 1.1MHz 0.85 32V 0.4V

Ч Ч

Ч

+

=

=

µ Ч

Ч

Ч

+

Output Capacitor Selection

The total output voltage ripple has two components: the
capacitive ripple caused by the charging and discharg-
ing on the output capacitor, and the ohmic ripple due to
the capacitor’s equivalent series resistance (ESR):

RIPPLE

RIPPLE(C)

RIPPLE(ESR)

OUT(MAX)

OUT(MAX)

IN(MIN)

RIPPLE(C)

OUT

OUT(MAX)

SW

V

V

V

I

V

V

V

C

V

f

=

+

×

and:

RIPPLE(ESR)

PEAK ESR(COUT)

V

I

R

where I

PEAK

is the peak inductor current (see the

Inductor Selection section).
The output voltage ripple should be low enough for the
FB_ current-source regulation. The ripple voltage should
be less than 200mV

P-P

. For ceramic capacitors, the out-

put voltage ripple is typically dominated by V

RIPPLE(C)

.
