MAX66020
ISO/IEC 14443 Type B-Compliant
1Kb Memory Fob
2
_______________________________________________________________________________________
ABSOLUTE MAXIMUM RATINGS
ELECTRICAL CHARACTERISTICS
(T
A
= -25°C to +50°C.) (Note 1)
Stresses beyond those listed under “Absolute Maximum Ratings” may cause permanent damage to the device. These are stress ratings only, and functional
operation of the device at these or any other conditions beyond those indicated in the operational sections of the specifications is not implied. Exposure to
absolute maximum rating conditions for extended periods may affect device reliability.
Note 1: System requirement.
Note 2: Measured from the time at which the incident field is present with strength greater than or equal to H
(MIN)
to the time at
which the MAX66020’s internal power-on reset signal is deasserted and the device is ready to receive a command frame.
Not characterized or production tested; guaranteed by simulation only.
Maximum Incident Magnetic Field Strength ..........141.5dBµA/m
Operating Temperature Range ...........................-25°C to +50°C
Relative Humidity ..............................................(Water Resistant)
Storage Temperature Range ...............................-25°C to +50°C
PARAMETER SYMBOL
CONDITIONS
MIN
TYP
MAX
UNITS
EEPROM
Programming Time
t
PROG
9
10
ms
Endurance
N
CYCLE
At
+25°C
200,000
Cycles
Data Retention
t
RET
40
Years
RF INTERFACE
Carrier Frequency
f
C
(Note 1)
13.553 13.560 13.567
MHz
Operating Magnetic Field Strength
H
At +25°C (Note 1)
123.5
137.5
dBμA/m
Power-Up Time
t
POR
(Note 2)
1.0
ms
