MAX6870/MAX6871
EEPROM-Programmable Hex/Quad
Power-Supply Sequencers/Supervisors with ADC
40 ______________________________________________________________________________________
Table 26. Register Map (continued)
REGISTER
ADDRESS
EEPROM
MEMORY
ADDRESS
READ/
WRITE
DESCRIPTION
0Bh 800Bh R/W IN6 secondary undervoltage/overvoltage detector threshold (MAX6870 only) (Table 4).
0Ch 800Ch R/W Secondary undervoltage/overvoltage selection (Tables 2, 4).
0Dh 800Dh R/W Threshold range selection (Tables 2–4).
0Eh 800Eh R/W PO1 (MAX6870 only) input selection (Table 10).
0Fh 800Fh R/W PO1 (MAX6870 only) input selection (Table 10).
10h 8010h R/W PO1 (MAX6870 only) input selection (Table 10).
11h 8011h R/W
PO1 (MAX6870 only) input selection, PO_ timeout period, and output type selection
(Tables 10, 23, and 25).
12h 8012h R/W PO2 (MAX6870 only) input selection (Table 11).
13h 8013h R/W PO2 (MAX6870 only) input selection (Table 11).
14h 8014h R/W PO2 (MAX6870 only) input selection (Table 11).
15h 8015h R/W
PO2 (MAX6870 only) input selection, PO_ timeout period, and output type selection (Tables
11, 23, and 25).
16h 8016h R/W PO3 (MAX6870)/PO1 (MAX6871) input selection—Product 1 (Table 12).
17h 8017h R/W PO3 (MAX6870)/PO1 (MAX6871) input selection—Product 1 (Table 12).
18h 8018h R/W PO3 (MAX6870)/PO1 (MAX6871) input selection—Product 1 (Table 12).
19h 8019h R/W PO3 (MAX6870)/PO1 (MAX6871) input selection—Product 2 (Table 13).
1Ah 801Ah R/W PO3 (MAX6870)/PO1 (MAX6871) input selection—Product 2 (Table 13).
1Bh 801Bh R/W PO3 (MAX6870)/PO1 (MAX6871) input selection—Product 2 (Table 13).
1Ch 801Ch R/W
PO3 (MAX6870)/PO1 (MAX6871) input selection—Products 1 and 2, PO_ timeout period,
and output type selection (Tables 12, 13, 23, 24, and 25).
1Dh 801Dh R/W PO4 (MAX6870)/PO2 (MAX6871) input selection—Product 1 (Table 14).
1Eh 801Eh R/W PO4 (MAX6870)/PO2 (MAX6871) input selection—Product 1 (Table 14).
1Fh 801Fh R/W PO4 (MAX6870)/PO2 (MAX6871) input selection—Product 1 (Table 14).
20h 8020h R/W PO4 (MAX6870)/PO2 (MAX6871) input selection—Product 2 (Table 15).
21h 8021h R/W PO4 (MAX6870)/PO2 (MAX6871) input selection—Product 2 (Table 15).
22h 8022h R/W PO4 (MAX6870)/PO2 (MAX6871) input selection—Product 2 (Table 15).
23h 8023h R/W
PO4 (MAX6870)/PO2 (MAX6871) input selection—Products 1 and 2, PO_ timeout period,
and output type selection (Tables 14, 15, 23, 24, and 25).
24h 8024h R/W PO5 (MAX6870)/PO3 (MAX6871) input selection—Product 1 (Table 16).
25h 8025h R/W PO5 (MAX6870)/PO3 (MAX6871) input selection—Product 1 (Table 16).
26h 8026h R/W PO5 (MAX6870)/PO3 (MAX6871) input selection—Product 1 (Table 16).
27h 8027h R/W PO5 (MAX6870)/PO3 (MAX6871) input selection—Product 2 (Table 17).
28h 8028h R/W PO5 (MAX6870)/PO3 (MAX6871) input selection—Product 2 (Table 17).
29h 8029h R/W PO5 (MAX6870)/PO3 (MAX6871) input selection—Product 2 (Table 17).
2Ah 802Ah R/W
PO5 (MAX6870)/PO3 (MAX6871) input selection—Products 1 and 2, PO_ timeout period,
and output type selection (Tables 16, 23, 24, and 25).
2Bh 802Bh R/W PO6 (MAX6870)/PO4 (MAX6871) input selection—Product 1 (Table 18).
2Ch 802Ch R/W PO6 (MAX6870)/PO4 (MAX6871) input selection—Product 1 (Table 18).
