MAX6870/MAX6871
Table 14 only applies to PO4 of the MAX6870 and PO2
of the MAX6871. Write a 0 to a bit to make the PO4/PO2
output independent of the respective signal (IN_ primary
or secondary thresholds, WDI1 or WDI2, GPI1–GPI4, MR, or other programmable outputs). See Table 15 for
Product 2. PO4 (MAX6870)/PO2 (MAX6871) deasserts
when Product 1 or Product 2 = 1.
EEPROM-Programmable Hex/Quad
Power-Supply Sequencers/Supervisors with ADC
24 ______________________________________________________________________________________
Table 14. PO4 (MAX6870)/PO2 (MAX6871) Output Dependency (Product 1)
REGISTER
ADDRESS
EEPROM
MEMORY
ADDRESS
BIT OUTPUT ASSERTION CONDITIONS
[0] 1 = PO4/PO2 assertion depends on IN1 primary undervoltage threshold (Table 2).
[1] 1 = PO4/PO2 assertion depends on IN2 primary undervoltage threshold (Table 3).
[2] 1 = PO4/PO2 assertion depends on IN3 primary undervoltage threshold (Table 4).
[3] 1 = PO4/PO2 assertion depends on IN4 primary undervoltage threshold (Table 4).
[4]
1 = P O4 ( M AX 6870 onl y) asser ti on d ep end s on IN 5 p r i m ar y und er vol tag e thr eshol d ( Tab l e 4) .
M ust b e set to 0 for the M AX 6871.
[5]
1 = P O4 ( M AX 6870 onl y) asser ti on d ep end s on IN 6 p r i m ar y und er vol tag e thr eshol d ( Tab l e 4) .
M ust b e set to 0 for the M AX 6871.
[6] 1 = PO4/PO2 assertion depends on watchdog 1 (Tables 27 and 28).
1Dh 801Dh
[7] 1 = PO4/PO2 assertion depends on watchdog 2 (Tables 27 and 28).
[0] 1 = P O4/P O2 asser ti on d ep end s on IN 1 second ar y und er vol tag e/over vol tag e thr eshol d ( Tab l e 2) .
[1] 1 = P O4/P O2 asser ti on d ep end s on IN 2 second ar y und er vol tag e/over vol tag e thr eshol d ( Tab l e 3) .
[2] 1 = P O4/P O2 asser ti on d ep end s on IN 3 second ar y und er vol tag e/over vol tag e thr eshol d ( Tab l e 4) .
[3] 1 = P O4/P O2 asser ti on d ep end s on IN 4 second ar y und er vol tag e/over vol tag e thr eshol d ( Tab l e 4) .
[4]
1 = PO4 (MAX6870 only) assertion depends on IN5 secondary undervoltage/overvoltage
threshold (Table 4). Must be set to 0 for the MAX6871.
[5]
1 = PO4 (MAX6870 only) assertion depends on IN6 secondary undervoltage/overvoltage
threshold (Table 4). Must be set to 0 for the MAX6871.
[6] 1 = PO4/PO2 assertion depends on GPI1 (Table 6).
1Eh 801Eh
[7] 1 = PO4/PO2 assertion depends on GPI2 (Table 6).
[0] 1 = PO4/PO2 assertion depends on GPI3 (Table 6).
[1] 1 = PO4/PO2 assertion depends on GPI4 (Table 6).
[2] 1 = P O4 ( M AX 6870 onl y) asser ti on d ep end s on P O1 ( Tab l e 10) . M ust b e set to 0 for the M AX 6871.
[3] 1 = P O4 ( M AX 6870 onl y) asser ti on d ep end s on P O2 ( Tab l e 11) . M ust b e set to 0 for the M AX 6871.
[4] 1 = P O4/P O 2 asser ti on d ep end s on P O3 ( M AX 6870) /P O 1 ( M AX 6871) ( Tab l es 12 and 13) .
[5] 1 = P O4/P O 2 asser ti on d ep end s on P O5 ( M AX 6870) /P O 3 ( M AX 6871) ( Tab l es 16 and 17) .
[6] 1 = P O4/P O 2 asser ti on d ep end s on P O6 ( M AX 6870) /P O 4 ( M AX 6871) ( Tab l es 18 and 19) .
1Fh 801Fh
[7] 1 = PO4/PO2 assertion depends on PO7 (MAX6870)/PO5 (MAX6871) (Table 20).
23h 8023h [0] 1 = P O4 ( M AX 6870 onl y) asser ti on d ep end s on P O8 ( Tab l e 21) . M ust b e set to 0 for the M AX 6871.
40h 8040h [3] 1 = PO4/PO2 asserts when MR = low (Table 7).
