MAX9392/MAX9393
Anything-to-LVDS Dual 2 x 2
Crosspoint Switches
6 _______________________________________________________________________________________
PIN NAME FUNCTION
17 ENA1
A1 Output Enable. Drive ENA1 high to enable the A1 LVDS outputs. An internal 435k Ω resistor pulls ENA1 low
when unconnected.
18 OUTA1
A1 LVDS Inverting Output. Connect a 100 Ω termination resistor between OUTA1 and OUTA1 at the receiver
inputs to ensure proper operation.
19 OUTA1
A1 LVDS Noninverting Output. Connect a 100 Ω termination resistor between OUTA1 and OUTA1 at the receiver
inputs to ensure proper operation.
21 ENA0
A0 Output Enable. Drive ENA0 high to enable the A0 LVDS outputs. An internal 435k Ω resistor pulls ENA0 low
when unconnected.
22 OUTA0
A0 LVDS Inverting Output. Connect a 100 Ω termination resistor between OUTA0 and OUTA0 at the receiver
inputs to ensure proper operation.
23 OUTA0
A0 LVDS Noninverting Output. Connect a 100 Ω termination resistor between OUTA0 and OUTA0 at the receiver
inputs to ensure proper operation.
26 INA0
LVDS/HSTL (MAX9392) or LVPECL/CML (MAX9393) Noninverting Input. An internal 128k Ω resistor to V
CC pulls
the input high when unconnected (MAX9392). An internal 68k Ω resistor to GND pulls the input low when
unconnected (MAX9393).
27 INA0
LVDS/HSTL (MAX9392) or LVPECL/CML (MAX9393) Inverting Input. An internal 128k Ω resistor to V
CC pulls the
input high when unconnected (MAX9392). An internal 68k Ω resistor to GND pulls the input low when
unconnected (MAX9393).
28 ASEL0
Input Select for A0 Output. Selects the differential input to reproduce at the A0 differential outputs. Connect
ASEL0 to GND or leave open to select the INA0 (
INA0) set of inputs. Connect ASEL0 to V
CC to select the INA1
( INA1) set of inputs. An internal 435k Ω resistor pulls ASEL0 low when unconnected.
30 INA1
LVDS/HSTL (MAX9392) or LVPECL/CML (MAX9393) Noninverting Input. An internal 128k Ω resistor to V
CC pulls
the input high when unconnected (MAX9392). An internal 68k Ω resistor to GND pulls the input low when
unconnected (MAX9393).
31 INA1
LVDS/HSTL (MAX9392) or LVPECL/CML (MAX9393) Inverting Input. An internal 128k Ω resistor to V
CC pulls the
input high when unconnected (MAX9392). An internal 68k Ω resistor to GND pulls the input low when
unconnected (MAX9393).
32 ASEL1
Input Select for A1 Output. Selects the differential input to reproduce at the A1 differential outputs. Connect
ASEL1 to GND or leave open to select the INA0 (
INA0) set of inputs. Connect ASEL1 to V
CC
to select the INA1
( INA1) set of inputs. An internal 435k Ω resistor pulls ASEL1 low when unconnected.
— EP Exposed Paddle (QFN Package Only). Connect to GND for optimal thermal and EMI characteristics.
Pin Description (continued)
