MAX5661
Single 16-Bit DAC with Current and Voltage
Outputs for Industrial Analog Output Modules
4 ________________________________________________________________________________________
PARAMETER SYMBOL CONDITIONS MIN TYP MAX UNITS
SETTLING TIME
C OUTV = 1nF,
R OUTV = 2k Ω
3 Bipolar output,
C
COMPV = 3.3nF,
to 0.1%
C
OUTV
= 1.2µF,
R
OUTV
= 2k Ω
5.44
ms
Bipolar output,
C
COMPV = 0nF,
to 0.1%
C OUTV = 100pF,
R OUTV = 2k Ω
244 µs
C OUTV = 1nF,
R OUTV = 2k Ω
1.8 Unipolar output,
C
COMPV
= 3.3nF,
to 0.1%
C OUTV = 1.2µF,
R OUTV = 2k Ω
3.64
ms
Voltage-Output Settling Time
Unipolar output,
C
COMPV = 0nF,
to 0.1%
C OUTV = 100pF,
R OUTV = 2k Ω
130 µs
R OUTI = 500 Ω 1.5
L OUTI = 1mH 1.66
L OUTI = 10mH 1.66
0 to 20.45mA
range to 0.1%
L
OUTI
= 1H 1.97
R OUTI = 500 Ω 1.43
L OUTI = 1mH 1.58
L OUTI = 10mH 1.58
Current-Output Settling Time
3.97mA to
20.45mA range
to 0.1%
L OUTI = 1H 1.73
ms
ELECTRICAL CHARACTERISTICS (continued)
(V CC = +5V, C COMPI = 22nF, V DDV = V DDCORE = +15V, V SSV = -15V, V DDI = +24V, V REF = +4.096V, V AGND = V DGND = V DUTGND =
V DACGND = 0V, R SERIES = 47Ω, OUTV loaded with 2kΩ || 100pF to AGND, OUTI loaded with 500Ω to AGND, T A = -40°C to +105°C,
unless otherwise noted. Typical values are at T A = +25°C. See the Typical Operating Circuit.) (Note 1)
