RF-TVMP20 TV Wall Mount
STEP 6 - Attach your TV to the wall plate
1 Holding the TV level, with the screen parallel to the wall. Place the arm assembly (B) over the wall plate (A) as
shown below.
2 Place the theaded cap (F) over the wall plate (A) and install the washer (P-F) and M6 x 60 mm screw (P-C).
You’ll need
HEAVY! You will need
assistance with this step.
Phillips screwdriver
Level
F Threaded Cap
P-C (1)
P-F (1)
