9901-UDX-OM (V1.15)
9901-UDX PRODUCT MANUAL
3-1
Chapter 3
Chapter 3
Operating Instructions
Overview
This chapter contains the following information:
•
Control and Display Descriptions (p. 3-1)
•
Accessing the 9901-UDX Card via Remote Control (p. 3-6)
•
Checking Card Information (p. 3-8)
•
Ancillary Data Line Number Locations and Ranges (p. 3-9)
•
9901-UDX Function Submenu List and Descriptions (p. 3-10)
•
Control and Display Descriptions
Note:
®
application notes covering comprehen-
sive setup of practical processing applications.
This section describes the user interface controls, indicators, and displays
(both on-card and remote controls) for using the 9901-UDX card. The
9901-UDX functions can be accessed and controlled using any of the user
interfaces described here.
The format in which the 9901-UDX functional controls, indicators, and
displays appear and are used varies depending on the user interface being
used. Regardless of the user interface being used, access to the 9901-UDX
functions (and the controls, indicators, and displays related to a particular
function) follows a general arrangement of Function Submenus under which
related controls can be accessed (as described in Function Submenu/
Parameter Submenu Overview below).
If you are already familiar
with using DashBoard or a
Cobalt Remote Control
Panel to control Cobalt
cards, please skip to
