9901-UDX Functional Description
1-10 9901-UDX PRODUCT MANUAL 9901-UDX-OM (V1.15)
Table 1-3 Scaler Function Conversions
Input
Format
Scaler Output Selections
SD
(NTSC/
PAL)
720p
720p
half-rate
720p
(film)
1080i 1080p
1080p
(film)
1080PsF
(film)
1080p 3G
525i 59.94 525i 59.94 720p 59.94 720p 29.97 720p 23.98
(4)
1080i 59.94 1080p 29.97 1080p 23.98
(4)
1080PsF 23.98
(4)
1080p 59.94
625i 50 625i 50 720p 50 720p 25 X 1080i 50 1080p 25 X 1080PsF 25 1080p 50
720p 60 X 720p 60 720p 30 720p 24
(4)
1080i 60 1080p 30 1080p 24
(4)
1080PsF 24
(4)
1080p 60
720p 59.94 525i 59.94 720p 59.94 720p 29.97 720p 23.98
(4)
1080i 59.94 1080p 29.97 1080p 23.98
(4)
1080PsF 23.98
(4)
1080p 59.94
720p 50 625i 50 720p 50 720p 25 X 1080i 50 1080p 25 X 1080PsF 25 1080p 50
720p 30 X 720p 60 720p 30 720p 24
(5)
1080i 60 1080p 30 1080p 24
(5)
1080PsF 24
(5)
1080p 60
720p 29.97 525i 59.94 720p 59.94 720p 29.97 720p 23.98
(5)
1080i 59.94 1080p 29.97 1080p 23.98
(5)
1080PsF 23.98
(5)
1080p 59.94
720p 25 625i 50 720p 50 720p 25 X 1080i 50 1080p 25 X 1080PsF 25 1080p 50
720p 24 X 720p 60 720p 30 720p 24 1080i 60 1080p 30 1080p 24 1080PsF 24 1080p 60
720p 23.98 525i 59.94 720p 59.94 720p 29.97 720p 23.98 1080i 59.94 1080p 29.97 1080p 23.98 1080PsF 23.98 1080p 59.94
1080i 60 X 720p 60 720p 30 720p 24
(4)
1080i 60 1080p 30 1080p 24
(4)
1080PsF 24
(4)
1080p 60
1080i 59.94 525i 59.94 720p 59.94 720p 29.97 720p 23.98
(4)
1080i 59.94 1080p 29.97 1080p 23.98
(4)
1080PsF 23.98
(4)
1080p 59.94
1080i 50 625i 50 720p 50 720p 25 X 1080i 50 1080p 25 X 1080PsF 25 1080p 50
1080p 30 X 720p 60 720p 30 720p 24
(5)
1080i 60 1080p 30 1080p 24
(5)
1080PsF 24
(5)
1080p 60
1080p 29.97 525i 59.94 720p 59.94 720p 29.97 720p 23.98
(5)
1080i 59.94 1080p 29.97 1080p 23.98
(5)
1080PsF 23.98
(5)
1080p 59.94
1080p 25 625i 50 720p 50 720p 25 X 1080i 50 1080p 25 X 1080PsF 25 1080p 50
1080p 24 X 720p 60 720p 30 720p 24 1080i 60 1080p 30 1080p 24 1080PsF 24 1080p 60
1080p 23.98 525i 59.94 720p 59.94 720p 29.97 720p 23.98 1080i 59.94 1080p 29.97 1080p 23.98 1080PsF 23.98 1080p 59.94
1080PsF 24 X 720p 60 720p 30 720p 24 1080i 60 1080p 30 1080p 24 1080PsF 24 1080p 60
1080PsF 25 625i 50 720p 50 720p 25 X 1080i 50 1080p 25 1080PsF 25 1080p 50
1080PsF 23.98 525i 59.94 720p 59.94 720p 29.97 720p 23.98 1080i 59.94 1080p 29.97 1080p 23.98 1080PsF 23.98 1080p 59.94
1080p 60 X 720p 60 720p 30 720p 24
(4)
1080i 60 1080p 30 1080p 24
(4)
1080PsF 24
(4)
1080p 60
1080p 59.94 525i 59.94 720p 59.94 720p 29.97 720p 23.98
(4)
1080i 59.94 1080p 29.97 1080p 23.98
(4)
1080PsF 23.98
(4)
1080p 59.94
1080p 50 625i 50 720p 50 720p 25 X 1080i 50 1080p 25 X 1080PsF 25 1080p 50
Notes: 1. The drop-down list choice of “Match Input” is used when no conversion is desired. For clarity, it is not redundantly listed here.
2. “X” denotes conversions not available or invalid conversions.
3. Interlaced formats rates listed are field rates. Progressive format rates listed are frame rates.
4. If the original material does not have a proper 3-2 cadence suitable for conversion to film rates, the conversion reverts to standard
de-interlacing. While this video can be converted to film rates, the resulting image motion will lack smoothness. Therefore, make
certain interlaced video is appropriately constructed for 3-2 reverse pulldown when converting video to film rates.
5. Formats using a 30/29.97 Hz progressive frame rate can be converted to a 24/23.98 Hz progressive frame rate, however some
image motion irregularity will appear in the converted output.
6. “NTSC” and “PAL” in this manual respectively denote 525i5994 and 625i50 SD analog formats, and informally 486i5994 and
575i50 SD-SDI video formats.
7. 3G rates above (as inputs or outputs) are for SDI or fiber ports only. Analog video input/output is limited to SD and HD only.
