Troubleshooting
3-68 9901-UDX PRODUCT MANUAL 9901-UDX-OM (V1.15)
Basic Troubleshooting Checks
Failures of a general nature (affecting many cards and/or functions
simultaneously), or gross inoperability errors are best addressed first by
performing basic checks before proceeding further. Table 3-3 provides basic
system checks that typically locate the source of most general problems. If
required and applicable, perform further troubleshooting in accordance with
the other troubleshooting tables in this section.
9901-UDX Processing Error Troubleshooting
Table 3-4 provides 9901-UDX processing troubleshooting information. If the
9901-UDX card exhibits any of the symptoms listed in Table 3-4, follow the
troubleshooting instructions provided.
In the majority of cases, most errors are caused by simple errors where the
9901-UDX is not appropriately set for the type of signal being received by the
card.
Note: The error indications shown below are typical for the corresponding error con-
ditions listed. Other error indications not specified here may also be displayed
on DashBoard™ and/or the 9901-UDX card edge status indicators.
Note: Where errors are displayed on both the 9901-UDX card and network remote
controls, the respective indicators and displays are individually described in
this section.
Table 3-3 Basic Troubleshooting Checks
Item Checks
Verify for power presence On both the frame Network Controller Card and the 9901-UDX, in all cases when
power is being properly supplied there is always at least one indicator illuminated. Any
card showing no illuminated indicators should be cause for concern.
Check Cable connection
secureness and connecting
points Make certain all cable connections are fully secure (including coaxial cable attachment
to cable ferrules on BNC connectors). Also, make certain all connecting points are as
intended. Make certain the selected connecting points correlate to the intended card
inputs and/or outputs. Cabling mistakes are especially easy to make when working
with large I/O modules.
Card seating within slots Make certain all cards are properly seated within its frame slot. (It is best to assure
proper seating by ejecting the card and reseating it again.)
Check status indicators and
displays On both DashBoard™ and the 9901-UDX card edge indicators, red indications signify
an error condition. If a status indicator signifies an error, proceed to the following tables
in this section for further action.
Troubleshoot by substitution All cards within the frame can be hot-swapped, replacing a suspect card or module
with a known-good item.
