9901-UDX-OM (V1.15) 9901-UDX PRODUCT MANUAL 2-1
Chapter 2
Chapter 2
Installation and Setup
Overview
This chapter contains the following information:
• Setting I/O Switches for Analog Audio (1-8) Ports (p. 2-1)
• Installing the 9901-UDX Into a Frame Slot (p. 2-2)
• Installing a Rear Module (p. 2-4)
• Connecting To Phoenix Terminal Connectors (p. 2-15)
• Setting Up 9901-UDX Network Remote Control (p. 2-15)
Note: The 9901-UDX is suitable for installation only in a 20-slot frame (Cobalt ® PN
HPF-9000, OG3-FR, or 8321-CN or equivalent).
Setting I/O Switches for Analog Audio (1-8) Ports
Notes: • This procedure is applicable only for 9901-UDX equipped with analog audio
options (for example, option +ANAIO). Refer to catalog or Fusion3G
®
man-
ual supplement Analog Audio/Video Options OPT-F3GAN-MS for more infor-
mation.
• All switches are set as inputs as factory default.
Analog audio options allow the 9901-UDX to be used with analog audio
inputs and/or outputs. The option provides for eight analog audio channel IN
or OUT, with each channel configurable as an input or output using DIP
switches S1 thru S8). The switches are located on the option piggyback card.
Note switch S1 thru S8 locations for AN-AUD I/O 1 thru AN-AUD I/O 8 shown in
Figure 2-1. For port to be used as an output, set switch to down position as
shown in Figure 2-1.
