9502-DCDA PRODUCT MANUAL
3-9
Operating Instructions
9502-DCDA Function Submenu List and Descriptions
9502-DCDA Function Submenu List and Descriptions
Table 3-2 individually lists and describes each 9502-DCDA function
submenu and its related list selections, controls, and parameters. Where
helpful, examples showing usage of a function are also provided. Table 3-2 is
primarily based upon using DashBoard™ to access each function and its
corresponding submenus and parameters.
Note:
All numeric (scalar) parameters displayed on DashBoard™ can be changed
using the slider controls,
arrows, or by numeric keypad entry in the corre-
sponding numeric field. (When using numeric keypad entry, add a return after
the entry to commit the entry.)
Note:
3G inputs, controls, and functions described in this section are not applicable
to 9502-DCDA-HD. In all other aspects, this version function identically as
described.
On DashBoard™ itself and in Table 3-2, the function submenu items are
organized using tabs as shown below.
The table below provides a quick-reference to the page numbers where each
function submenu item can be found.
Some functions use sub-tabs to help maintain clarity and organization. In these instances,
Table 3-2 shows the ordinate tab along with its sub-tabs. Highlighted sub-tabs indicate that
controls described are found by selecting this sub-tab (in this example, the Downmixer
sub-tab on the Audio Control page).
Function Submenu Item
Page
Function Submenu Item
Page
3-19
3-10
3-20
3-12
3-23
3-26
3-27
3-18
