1
Technical Specifications
1-12 9502-DCDA PRODUCT MANUAL 9502DCDA-OM (V1.3)
9502-DCDA Rear I/O Modules
The 9502-DCDA physically interfaces to system video connections at the rear
of its frame using a Rear I/O Module.
All inputs and outputs shown in the 9502-DCDA Functional Block Diagram
(Figure 1-1) enter and exit the card via the card edge backplane connector.
The Rear I/O Module breaks out the 9502-DCDA card edge connections to
BNC and other connectors that interface with other components and systems
in the signal chain.
The full assortment of 9502-DCDA Rear I/O Modules is shown and described
in 9502-DCDA Rear I/O Modules (p. 2-4) in Chapter 2, “Installation and
Setup”.
Technical Specifications
Table 1-1 lists the technical specifications for the 9502-DCDA Up/Down/
Cross Format Converter, Video/Audio In with Frame Sync card.
Table 1-1 Technical Specifications
Item Characteristic
Note: 3G (SMPTE 424M) specifications are applicable for card model 9502-DCDA-3G only.
Part number, nomenclature 9502-DCDA Up/Down/Cross Format Converter, Video/Audio In
with Frame Sync
Installation/usage environment Intended for installation and usage in frame meeting openGear™
modular system definition.
Power consumption < 18 Watts maximum
Installation Density Up to 20 cards per 20-slot frame
Environmental:
Operating temperature:
Relative humidity (operating or storage): 32° – 104° F (0° – 40° C)
< 95%, non-condensing
Frame communication 10/100 Mbps Ethernet with Auto-MDIX.
Indicators Card edge display and indicators as follows:
• 4-character alphanumeric display
• Status/Error LED indicator
• Input Format LED indicator
