3
Control and Display Descriptions
3-2 9502-DCDA PRODUCT MANUAL 9502DCDA-OM (V1.3)
Function Submenu/Parameter Submenu Overview
The functions and related parameters available on the 9502-DCDA card are
organized into function submenus, which consist of parameter groups as
shown below.
Figure 3-1 shows how the 9502-DCDA card and its submenus are organized,
and also provides an overview of how navigation is performed between cards,
function submenus, and parameters.
Figure 3-1 Function Submenu/Parameter Submenu Overview
9502-DCDA
Submenu a Submenu b Submenu z • • •
Individual Parameters
Each submenu consists of groups of parameters
related to the function submenu. Using the “Proc
Control” function submenu example, the individual
parameters for this function consist of various video
processor parameters such as Gain, Lift, Saturation,
and so on.
If using DashBoard™ or a Remote Control Panel, the
desired 9502-DCDA card is first selected.
The desired function submenu is next
selected.
Function Submenus consist of parameter
groups related to a particular 9502-DCDA
card function (for example, “Proc Control”).
