Chapter 1

Chapter 1

Introduction

Overview

This manual provides installation and operating instructions for the
9033 Input Processing Analog to Digital Video Converter with Audio
Embedding and Dolby

Decoding Option card (also referred to herein as the

9033).

Note:

This manual also covers the 9033-DEC, which is the 9033 card equipped with
Dolby

decoding as an option. Where applicable, descriptions related exclu-

sively to either the 9033 or the 9033-DEC are respectively denoted by (9033
only) or (9033-DEC only). In all other aspects, both the 9033 and 9033-DEC
function identically as described in this manual.

This manual consists of the following chapters:

•

Chapter 1, “Introduction” – Provides information about this manual
and what is covered. Also provides general information regarding the
9033.

•

Chapter 2, “Installation and Setup” – Provides instructions for
installing the 9033 in a frame, and optionally installing 9033 Rear I/O
Modules.

•

Chapter 3, “Operating Instructions” – Provides overviews of
operating controls and instructions for using the 9033.

This chapter contains the following information:

•

9033 Card Software Versions and this Manual (p. 1-2)

•

Manual Conventions (p. 1-3)
