9033-OM (V4.0) 9033 PRODUCT MANUAL 1-17
Introduction
9033 Functional Description
Table 1-1 Supported Audio and Video Formats
Item Description/Specification
Input / Output Video Raster Structure: Frame Rate:
1080PsF 23.98; 24
1080p 23.98; 24
1080i
(1)
25; 29.97; 30
720p 23.98; 24; 25; 29.97; 30; 50; 59.94; 60
486i
(1, 2)
29.97
575i
(1, 2)
25
Embedded Audio The 9033 supports all four groups (16 channels) of embedded audio at
full 24-bit resolution in both SD (with extended data packets) and HD.
Analog Audio The 9033 supports 8 channels of balanced (differential) analog audio.
The analog audio is encoded such that a +24 dBu input is equivalent to
digital 0 dBFS.
Discrete AES Audio Input The 9033 can accept 16 channels (8 pairs) of discrete AES audio on
75
Ω
BNC connections. Sample rate conversion can be employed to
account for minor clock rate differences in the AES stream and the
input video stream.
Note: The AES signal must have a nominal rate of approximately
48 kHz. The 9033 does not support AES input at 32 kHz,
44.1 kHz, 96 kHz or 192 kHz rates.
Discrete AES Audio Output The 9033 can provide 16 channels (8 pairs) of discrete AES audio on
75
Ω
BNC connections.
(9033-DEC only) Dolby ® E/
Dolby ® Digital™ Audio Input
Decode
The 9033-DEC provides up to 10 decoded AES channels when valid
Dolby
® E or Dolby ® Digital™ audio is received on either discrete AES
or embedded inputs with corresponding metadata.
(1) All rates displayed as frame rates; interlaced (“i”) field rates are two times the rate value shown.
(2) 9033-SD support only NTSC and PAL SD rates.
