Moog Music 500 Series Analog Delay - Manual (Page 17)

17
MIDI CONTROL CHANGE (CC) MESSAGES
The settings of the Analog Delay can be controlled by MIDI Control Change
(CC) messages. In addition to the front panel controls, there are a number
of advanced features that can be enabled and edited with Control Change
messages.
A MIDI CC message has both a CC# from 0 to 127 and a value from 0-127.
The CC values that affect panel controls replace the physical setting of
the front panel controls. When the corresponding front panel control is
changed after receiving a MIDI CC message, the value will return to that
panel control.
wARNING: Moving a front panel control when the control is simultaneously
receiving MIDI CC messages will result in conflicting values.
MIDI CC NUMBERS AND VALUES
PARAMETER MSB
CC#
LSB
CC#
TYPE VALUES PERSI-
STENT
Time Slew Rate 5 37 Continuous 0-16383
Time 12 44 Continuous 0-16383
Feedback 13 45 Continuous 0-16383
LFO Rate 15 47 Continuous 0-16383
LFO Duty Cycle 20 52 Continuous 0-16383
Time Short/Long 74 Discrete [2] 0(0.5x),64(1.0x)
Time Sync on/off 76 Discrete [2] 0(off), 64(on)
Time Multiplier 75 Discrete [4] 0(1x),32(2x),
64(4x),96(8x)
LFO MIDI Note
Reset On/Off 73 Yes
Yes
Yes
Yes
Time Clock Div. 77 Discrete [21] See MIDI Clock
Division Chart
LFO Clock Div. 79 Discrete [21] See MIDI Clock
Division Chart
LFO Sync on/off 78 Discrete [2]
Discrete [2] 0(off), 64(on)
0(off), 64(on)
Tap Tempo A 83 1 Shot 0-127 = a Tap
MIDI Note Mode
Select 82 Discrete [3] 0(off),
43(delay time)
LFO Shape 17 Discrete [8] 0(Off),16(Sine)
32(Triangle),
48(Square),
64(Saw),
80(Ramp),
96(S&H),
112(Smth. S&H)
LFO Phase Reset 72 1-Shot Send value 64
when UI button
clicked, or when
host automation
transitions from
Off(valueto on(value>half)
Pitch Bend Amt. 80 Discrete [8] 0(off), 16(2 semi-
tones), 32(3 semi)
48(4 semi), 64(5
semi), 80(7 semi)
96(12 semi),
112(24 semi)
