Handrails, 36" platform assembly – Grain Systems Bucket Elevtors, Conveyors, Series II Sweeps PNEG-1295 User Manual
Page 18
18
PNEG-1295 16" - 36" Platform
5. 36" PLATFORM ASSEMBLY
Handrails
Attach handrails to handrail posts in position as shown in
with 3/8" x 1" hardware.
Attach latch assembly for deck hatch door to lower handrail next to the center vertical post using
5/16" x 1" hardware. Now go back and tighten all hardware.
Figure 5G 36" Platform
Latch Assembly
(GSB30120)
Handrail,
36" Discharge
(HP36DH)
Spacer, 36" Discharge
Handrail (HP36DHS)
Handrail, 36" HP
Long (HP36LH)
Handrail, 36"
Short (HP36SH)
