9. Parts List
PNEG-1434 6", 8" and 10" Roof Augers 35
10" Roof Auger Parts
Ref # Part # Description and System
1 GK3397 90° Spout
2 S-7382 Spout 5/16"-18 Nylock Nut
3 S-2741 Spout 5/16"-18 x 1-1/2" Hex Bolt
4 GK6998 Horizontal Power Head Tube
5 S-968 Bearing Plate 3/8"-16 Serrated Flange Nut
6 GK7014 Pivot Tube Spacer
7 S-6994 Pivot Tube Cotter Pin
8 GK7013 Motor Mount Pivot Rod
9 GK7012 Motor Mount Adjustment Rod
10 GK6942 Motor Mount Adjuster
11 S-240 Motor Mount Adjuster 1"-8 Nut
12 S-7835 Motor Mount Adjuster 1" Flat Washer
13 GK6986 Motor Mount Plate
14 GK7017 Bearing Plate
15 S-7469 Bearing Plate 3/8"-16 x 1" Hex Bolt
16 S-8760 Discharge Bearing 1/2"-13 x 1-1/2" Hex Bolt
17 S-248 Belt Guard Bracket 3/8" Flat Washer
18 S-2071 Belt Guard Bracket 3/8"-16 x 1-1/4" Hex Bolt
19 GK1343 Discharge Bearing 1-1/2" I.D. with 2 Hole Flangette
20 S-8314 Flight Connecting 1/2"-13 x 3-1/2" Grade 8 Hex Bolt
21 S-236 Discharge Bearing 1/2" Lock Washer
22 S-3729 1/2"-13 Hex Nut YDP Grade 5
23 S-8315 Flight Connecting 1/2"-13 Stover Nut
24 GK1289 Drive Shaft 1-1/2" O.D. x 11-1/2"
25 S-9181 Drive Shaft 3/8" x 3" Square Key
26 GK7018 Belt Guard Mounting Bracket
27 S-9065 Belt Guard 3/8"-16 x 1" Grade 5 Bolt
28 GK1345 Sheave 15" x 1-1/2"
29 GK1346 B57 V-Belt
30 GK7005 Belt Guard
31 GK5143 Discharge Flight
32 GK1951 Connecting Shaft 1-1/2" O.D. x 11-1/2"
33 S-7886 Hanger Bearing 5/8"-11 x 1-3/4" Grade 8 Bolt
34 S-3208 Hanger Bearing 5/8" Lock Washer
35 GC06396 Hanger Bearing
36
GK3708 Extension Flight 10'' x 16' - System
GK3706 Extension Flight 10'' x 21' - System
37 GK2907 Intake Shaft 1-1/2" O.D. x 9-1/2"
38 S-3729 1/2"-13 Hex Nut YDP Grade 5
39 S-236 Intake Bearing 1/2" Lock Washer
40 GK5653 Intake 1-1/2" Bearing with 3 Hole Flangette
41 GK4127 Hopper
42 S-2741 Hopper Connecting Band 5/16"-18 x 1-1/2" Hex Bolt
43 S-1147 Hopper Connecting Band 5/16" Lock Washer
44 S-396 Hopper Connecting Band 5/16"-18 Hex Nut
45 GK1057 Support Stand 10" x 2" 12 Gauge Half Band
46 S-2741 Support Stand 5/16"-18 x 1-1/2" Grade 5 Bolt
47 GK7303 Support Stand Short
48 S-1147 Support Stand 5/16" Lock Washer
49 S-396 Support Stand 5/16"-18 Hex Nut
50 GK3670 Inspection Cover Half Band
51 S-7382 Inspection Cover 5/16"-18 Lock Nut
52 GK7304 Support Stand Medium
53 S-7149 Inspection Cover 5/16"-18 x 1-3/4" Grade 5 Bolt
54 GK7305 Support Stand Tall
55 S-456 Power Head Connecting 3/8"-16 Hex Nut
56 S-7520 Power Head Connecting 3/8"-16 x 1" Bin Bolt
57
GK7095 Auger Tube 10" x 7' 6" - System (10'' x 11')
GK7098 Auger Tube 10" x 12' 6" - System (10'' x 16')
GK7099 Auger Tube 10" x 17' 6" - System (10'' x 21')
