9. Parts List
PNEG-1434 6", 8" and 10" Roof Augers
31
6" Roof Auger Parts
Ref #
Part #
Description and System
1
GK7173
90° Spout
2
S-7382
Spout 5/16"-18 Nylock Nut
3
S-2741
Spout 5/16"-18 x 1-1/2" Hex Bolt
4
GK6996
Horizontal Power Head Tube
5
S-3611
Bearing Plate 5/16"-18 Serrated Flange Nut
6
GK7014
Pivot Tube Spacer
7
S-6994
Pivot Tube Cotter Pin
8
GK7058
Motor Mount Pivot Rod
10
GK7060
Motor Mount Adjuster
11
S-3234
Motor Mount Adjuster 3/4"-10 Nut
12
S-866
Motor Mount Adjuster 3/4" Flat Washer
13
GK7052
Motor Mount Plate
14
GK7061
Bearing Plate
15
S-1196
Bearing Plate 5/16"-18 x 1" Hex Bolt
16
S-7837
Discharge Bearing 7/16"-14 x 1-1/2" Hex Bolt
17
S-845
Belt Guard Bracket 5/16" Flat Washer
18
S-1196
Belt Guard Bracket 5/16"-18 x 1" Hex Bolt
19
GK1049
Discharge Bearing 1" I.D. with 2 Hole Flangette
20
S-7687
Flight Connecting 3/8"-16 x 2" Grade 8 Hex Bolt
21
S-7014
Discharge Bearing 7/16" Lock Washer
22
S-7332
Discharge Bearing 7/16"-14 Nut
23
S-8251
Flight Connecting 3/8"-16 Stover Nut
24
GK2025
Drive Shaft 1" O.D. x 10"
25
S-4513
Drive Shaft 1/4" x 2" Square Key
26
GK7062
Belt Guard Mounting Bracket
27
S-9065
Belt Guard 3/8"-16 x 1" Grade 5 Bolt
28
GK1321
Sheave 12" x 1"
29
GK1323
B48 V-Belt
30
GK7005
Belt Guard
31
GK2854
Discharge Flight 6'' x 11' - System
GK2855
Discharge Flight 6'' x 16' - System
GK2856
Discharge Flight 6'' x 21' - System
37
GK1117
Intake Shaft 1" O.D. x 7"
38
S-396
Intake Bearing 5/16"-18 Hex Nut
39
S-1147
Intake Bearing 5/16" Lock Washer
40
GK1583
Intake 1" Bearing with 3 Hole Flangette
41
GK3995
Hopper
42
S-1146
Hopper Connecting Band 5/16"-18 x 1" Hex Bolt
43
S-1147
Hopper Connecting Band 5/16" Lock Washer
44
S-396
Hopper Connecting Band 5/16"-18 Hex Nut
45
GK1053
Support Stand 6" x 2" 12 Gauge
Half Band
46
S-2741
Support Stand 5/16"-18 x 1-1/2" Grade 5 Bolt
47
GK7297
Support Stand Short
48
S-1147
Support Stand 5/16" Lock Washer
49
S-396
Support Stand 5/16"-18 Hex Nut
52
GK7298
Support Stand Medium
54
GK7299
Support Stand Tall
55
S-3611
Power Head Connecting 5/16"-18 Serrated Flange Nut
56
S-275
Power Head Connecting 5/16"-18 x 3/4" Bin Bolt
57
GK7082
Auger Tube 6'' x 9' - System (6'' x 11')
GK7083
Auger Tube 6'' x 14' - System (6'' x 16')
GK7084
Auger Tube 6'' x 19' - System (6'' x 21')
