1. Bottom Module

PNEG-1404 Vision Series Model 2300 Portable Dryers

23

Bottom Auger

Figure 1T

2

3

2

4

2

Bottom auger center bearing and support

Bottom auger rear bearing

Bottom auger (view from center

of dryer to the forward end)

Bottom auger (view from center

of dryer to the rear end)

5

7

6

8

7

1
