1. Bottom Module
12
PNEG-1404 Vision Series Model 2300 Portable Dryers
Meter Roll Upper Shield Assembly
Figure 1I Close Up of Meter Roll Upper Shield Assembly
Inside (Plenum) Screens/Plenum Closure Doors
Assembly Parts List
and
Ref #
Part #
Description
Qty
2314
2318
2320
2322
2326
1
D31-0055
Column Bulkhead
12
16
18
20
24
2
D01-0101
Garner Bulkhead
12
16
18
20
24
3
D31-0307
Column End Panel
4
4
4
4
4
4
D01-0126
Screen, Plenum Top, Gauge, 094
14
18
20
22
26
5
D31-0012
Screen, Plenum Wall, Gauge, 094
14
18
20
22
26
6
D01-1225
Screen, Plenum Bottom, Gauge, 094
14
18
20
22
26
7
D01-0004
Gusset Plate
16
20
22
24
28
8
D21-0011
Frame Rail, 14' Right
1
8
D31-0044
Frame Rail, 18' Right
1
8
D61-0002
Frame Rail, 20' Right
1
8
D101-0002
Frame Rail, 22' Right
1
8
D71-0001
Frame Rail, 26' Right
1
9
D21-0010
Frame Rail, 14' Left
1
9
D31-0043
Frame Rail, 18' Left
1
9
D61-0001
Frame Rail, 20' Left
1
9
D101-0001
Frame Rail, 22' Left
1
9
D71-0002
Frame Rail, 26' Left
1
10
D01-0007
Corner Leg Portable Dryer
6
6
6
8
8
11
D01-0012
Hitch Bracket Right
1
1
1
1
1
12
D01-0011
Hitch Bracket Left
1
1
1
1
1
13
D01-0008
Front and Rear Frame Tie Channel
4
4
4
6
6
14
D01-2435
Front Bearing Plate 2008
1
1
1
1
1
15
D01-0005
Side Leg Portable Dryer
10
14
16
16
20
16
D01-0109
Hopper Bulkhead
12
16
18
20
24
17
D01-0050P
Connector Sheet, Perforated
14
18
20
22
26
*18 and 19
D01-1180
Meter Roll Upper Shield Assembly
14
18
20
22
26
18
D01-0431
Meter Roll Strike Off Plate
1/Assembly
19
D01-1226
Meter Roll Shield 1995 Style
1/Assembly
20
D01-1214
Plenum Closure Door, Rear
1
1
1
1
1
20a
D01-1134
Plenum Closure Door
6
8
9
10
12
21
DC-974
Danger Foot in Auger Decal
2
2
2
2
2
22
D01-1217
Plenum Closure Door Rear Frame Angle
1
1
1
1
1
23
D61-0038
Bulkhead Stiffener Bar
24
32
36
40
48
* Ref #18 and 19 together make up the meter roll upper shield assembly.
16
17
18
19
19
18
17
