Rough Country 1079 - Manual

XJ FRONT ADJ TRACK BAR KIT FOR 4”- 6” LIFT
92107900
Thank you for choosing Rough Country for your Jeep off road needs.
Please read all the instructions before beginning the installation.
PRODUCT USE INFORMATION
We will be happy to answer any questions regarding our products by calling us @ 800-222-7023. Rough Country will
not be responsible for any product that is altered. This kit is for use with vehicles lifted 4-6” of lift.
KIT CONTENTS
1-TRACK ROD BRACKET
1-ADJ TRACK ROD BODY & END
TOOLS NEEDED
18mm Socket / Wrench
19mm Socket / Wrench
24mm Socket / Wrench
1-POLY BAG CONTAINING:
2-Bushings
1-7/16” Sleeve
1-Heim End
2-Heim Spacers
2-7/16” X 2 3/4” Bolt
4-7/16” Flat Washers
2-7/16” Lock Nut
1-3/4” Jam Nut
INSTALLATION INSTRUCTIONS
1. Remove the track rod from the axle using a 15mm wrench /socket.
2. Remove the cotter pin from the track rod end on the frame and remove the nut using a 18mm socket (frame).
3. Remove the stock track rod bracket from the drivers side of the vehicle by removing the two side nuts on the frame
using a 18mm socket and the two lower bolts shown in Photo 1 on the bottom of the frame rail using a 15mm
wrench / socket. Retain the stock hardware for reuse.
4. Place the new track rod bracket in place on the studs on the side of the frame rail and tighten using a 18mm socket.
See Photo 2.
PHOTO 1 PHOTO 2
