FRONT INSTALLATION INSTRUCTIONS
1. Lift the front of the vehicle using a jack and support the vehicle with jack stands, so that the front wheels are off the ground
2. Remove the front tires/wheels., using a 21mm deep well socket
3. Starting on the driver side, remove the ABS sensor bracket from the top of the knuckle using a 10mm socket. See Photo 1. Next
remove the ABS wire from the plastic clip. Remove the bracket from the control arm using a 10mm wrench. See Photo 2.
4. Using a 21mm wrench remove the tie-rod nut and strike the side of the mount to dislodge the taper lock on the tie-rod. See
Photo 3.
5. Remove the brake caliper from the factory knuckle using a 18mm socket. See Photo 4. Hang or tie the caliper out of the way.
6. Remove the ABS sensor from the bearing assemble using a 8mm allen wrench. See Photo 5.
7. Remove the upper ball joint nut using a 18mm wrench, strike the knuckle on the side to dislodge the ball joint. See Photo 6.
PHOTO 1
PHOTO 1 PHOTO 2
PHOTO 3 PHOTO 4
PHOTO 5 PHOTO 6
