Rough Country 208 - Manual (Page 11)

12. Secure the spacer in the mount and washer using the supplied 3/8” x 3 3/4” bolts and lock nuts. See Photo 7.
13. Reinstall the coil spring.
14. Install the brake line spacer as shown in Photo 8 with the supplied 8mm x 65mm bolt and locking nut. Tighten with a
13mm socket/ wrench.
15. Install the supplied sleeves in the sway bar link and install on the frame using the stock hardware.
16. Place the supplied washer on the head of the supplied 12mm x 65mm bolt and install on the sway bar with the nut on
the sway bar. Tighten using a 18mm & 19mm wrench.
17. Remove the track rod from the axle using a 21mm socket/wrench. Install the new bracket as shown in Photo 9 with the
supplied crush sleeve and stock hardware with flanged nut towards middle of vehicle. Do not tighten at this time. Make
sure the bracket is square as shown in Photo 9. Mark and drill the two holes using a 15/32” drill bit.
18. Secure with the supplied 7/16” x 1” bolts, washers /nuts as shown in Photo 10. Raise the axle to align the track rod
with the new bracket and install using supplied 9/16” x 3 1/2” bolt, washers, and nut into the top hole of the track bar
bracket. Tighten using a 21mm socket & 22mm wrench. Tighten 7/16” bolts to 52 ft. lbs and the 9/16” bolt to 82 ft. lbs.
19. Install the shock relocation bracket as shown in the factory shock location with the supplied 5/8” x 1 1/2” bolt, washers
and lock nut on the bottom of the shock mount. See Photo 11.
20. Install the supplied 14mm x 75mm bolt, washers and lock nuts in the stock shock mount. See Photo 12.
21. Install the tires/wheels.
22. Jack up the vehicle to remove the jack stands. Remove the jack stands and lower the vehicle to the ground.
Photo 12 Photo 11
Photo 8 Photo 7
Photo 9 Photo 10
