Rough Country 1173 - Manual (Page 2)

4. Using a 18mm socket, remove the 4 bolts holding the bumper to the frame horn on the driver and passenger side.
See Photo 3.
5. Locate the plug for the fog lights and unplug. Remove bumper. See Photo 4.
Photo 3 Photo 4
6. Using a 15mm socket, remove the nuts holding the impact bar to the front bumper cover. Retain stock hardware.
Separate the impact bar from the bumper cover. See Photo 5.
7. Remove the stock toe hook brackets if equipped. Place the front brackets shown in Photo 6 into the factory frame
horn to check for proper fit. Due to differences in the manufacturing inconsistencies enlarging the holes in the frame
horn may be needed. Enlarge the hole by using a rotary tool, or round file.
8. Place the 2 front bumper brackets into the bumper cover as shown in Photo 6.
9. Find the driver side winch plate bracket. Install the bracket, using the 9/16” x 1.5” bolt, flat washer, and nut. Hand
tighten at this time. Repeat on the passengers side. See Photo 7 & 8.
Photo 5 Photo 6
Photo 7 Photo 8
