Rough Country 1030 - Manual

JEEP JK EXHAUST EXTENSIONS
Thank you for choosing Rough Country for your suspension needs.
This Exhaust Extension kit is intended to gain clearance on the exhaust on the 2012 JK models. Changes in the
this year model allow the front driveshaft to come in contact with the exhaust with the addition of most lift kits.
This kit will relocate the crossover pipe on the exhaust away from the driveshaft allowing for more clearance.
Rough Country recommends a certified technician install this system. In addition to these instructions, professional
knowledge of disassemble/reassembly procedures as well as post installation checks must be known. Always allow the
exhaust to cool before initiating installation.
Please read instructions before beginning installation. Be sure you have all
needed parts and know where they go. Please review tools needed list and make sure you have needed tools.
If question exist we will be happy to answer any questions concerning the design, function, and correct use of our prod-
ucts by calling 1-800-222-7023.
92103000
Tools Needed:
Air Chisel
13mm Socket / Wrench
INSTALLATION INSTRUCTIONS
1. Loosen the exhaust clamp on the drivers side as shown using a 13mm wrench.
2. Remove the nipple as shown on the drivers side pipe as shown using an air chisel. See Photo 2.
PHOTO 1 PHOTO 2
REMOVE THE NIPPLE FROM THE EXHAUST
Kit Contents:
1-Driver Side Exhaust Extension
1-Pass Side Exhaust Extension
1-Poly Bag Containing:
2-8mm x 80mm Bolts
2-8mm x 100 Bolts
