FRONT INSTALLATION INSTRUCTIONS
1. Chock the rear wheels and jack up the front of the vehicle and support the vehicle with jack stands so that the front
wheels are off the ground.
2. Using a 19mm deep well socket remove the front tires/wheels,
3. Using a 18mm socket and wrench remove the bottom sway bar bolts. Retain hardware for later use. See Photo 1
4. Using a 18mm socket and wrench remove the lower shock bolt. See Photo 2. Retain the lower hardware for reuse.
5. Push down on the axle to allow room for the coils to be removed. Remove coil springs, and factory spring isolator.
6. Install the new coil spring in the stock location with the factory isolator as shown See Photo 3.
7. Install the new Rough Country Performance 2.2 shocks in the factory location with the factory bolt in the lower
shock mount and tighten using a 18mm socket and wrench. See Photo 4.
8. Reinstall the front tires/wheels and tighten to factory specifications.
9. Remove the jack stands and lower the vehicle to the ground. Install the sway bar links on the sway bar using
factory hardware using a 18mm wrench after the vehicle is on the ground. Do not install the sway bar link on
the sway bar until the sway bar is on the ground.
10. The draglink must be adjusted to center the steering wheel BEFORE the vehicle is driven. Failure to do so will
cause a computer error with the Jeep’s traction control system and will result in odd handling and poor performance.
Photo 1 Photo 2
Photo 3 Photo 4
