Rough Country 7599 User Manual
Page 3
11. Remove the sway bar using a 15mm wrench. See Photo 9.
12. Strike to dislodge the lower ball joint as shown in Photo 10 and remove the lower nut and remove the knuckle from
the vehicle.
13. Remove the coil spring
14. Leaving coil spring isolator in place, install new spacer into top of coil spring. Rotate machined cutout 180 deg. from
spring pigtail. See Photo 11.
15.
Install coil spring into spring bucket, align machined cutout in spacer with lip on coil bucket. See Photo 12.
16. Use jack to raise lower control arm by compressing the coil spring. See Photo 13
17. Attach upper control arm to the knuckle using stock hardware and tighten using 18mm socket. See Photo 14
PHOTO 10
PHOTO 9
PHOTO 11
PHOTO 12
PHOTO 13
PHOTO 14
