OTPN-2000C (Forward Optical Receiver)
RF OUTPUT & PERFORMANCE PARAMETERS:
Frequency Range (& Flatness)
54-1,000MHz, 85-1,000MHz or 45-1,000MHz (±1.0dB)
Output Level *
+46dBmV @ 550MHz *
Return Loss
>16dB
Impedance 75-Ohm
CNR*
>53dB @ -1dBm; >49dB @ -6dBm optical input*
CSO*
>64dBc @ -1dBm optical input*
CTB*
>69dBc @ -1dBm optical input*
RF Gain Adjustment
0-18dB (with Model# 95080x plug-in pad)
Slope Adjustment
4-17dB (with Model# 95180x plug-in equalizer)
RF Test Point
-20dB (internal)
RF Output
Connector Type F
* NOTE: Typical; Measured with 12dB slope to 1,000MHz; +8dBm optical transmitter with OMI @ 2.8%, and;
77 NTSC Channel loading to 550MHz & digital loading to 1,000MHz (-6 dB below analog).
OPTICAL PARAMETERS:
Wavelength 1280-1600nm
Optical Input
Power Range -6 dBm to +3dBm
Return Loss
>60dB with APC type connector
Optical Input Power Test Point
1 V/mW (external)
Optical Connector
SC/APC standard; FC/APC optional); 8° APC
ELECTRICAL, ENVIRONMENTAL & MECHANICAL PARAMETERS:
Dimensions
3" H x 4.5" W x 8" D (7.75cm x 12.1cm x 20.5cm)
Weight
2.1 lb. (0.96 kg)
Operating Temperature Range
-10 to +55°C
Enclosure IP Rating
IP20
Powering
90 - 240VAC @ 50-60 Hz via IEC320 connector
Power Dissipation
19W maximum
Cooling
Fan cooled, forced air (Field-replaceable)
OTPT-300A Series (Return Optical Transmitters)
RF INPUT & PERFORMANCE PARAMETERS:
Frequency Range (& Flatness) via Diplexer
5-42MHz (NTSC) / 5-65MHz (PAL) (±1.0dB)
Freq. Range (& Flatness) via Ext. Aux. RF Input
5-300MHz (±1.0 dB)
Return Loss
>16dB @ 5-42MHz, 5-30MHz or 5-65MHz
OPTICAL PARAMETERS:
Return Loss
>60dB with APC type connector
Laser Power Test Point 1
V/mW (external)
Laser Current Test Point 1
V/50 mA (external)
Optical Connector
SC/APC standard; FC/APC optional); 8° APC
ELECTRICAL, ENVIRONMENTAL & MECHANICAL PARAMETERS:
Dimensions
2.5" H x 0.75" W x 7.1" D (6.25cm x 1.8cm x 18cm)
Weight
0.5 lb. (0.2 kg)
Powering (& Power Dissipation)
via OTPN-2000 (4W maximum)
OTPT-304A & OTPT-305A SPECIFICATIONS (DFB Return Optical Transmitters)
RF INPUT & PERFORMANCE PARAMETERS:
Return Path NPR (DFB)**
>15dB over 41dB NPR **
NPR 41dB Threshold
-57dBmV/Hz
**NOTE: As measured with 10dB of fiber and OTOR-300 High Sensitivity Return Band Receiver
OPTICAL PARAMETERS:
Wavelength (OTPT-304A)
1310nm ±20nm
Laser Type; Optical Output Power (OTPT-304A)
Distributed Feedback: +3.0mW ±0.5 mW
Wavelength (OTPT-305A) 1
1550nm ±20nm
Laser Type; Optical Output Power (OTPT-305A)
Distributed Feedback: +2.0 mW ±0.5 mW
OTPT-347A thru OTPT-361A SPECIFICATIONS (CWDM Return Optical Transmitters)
RF INPUT & PERFORMANCE PARAMETERS:
Return Path NPR (DFB)**
>15dB over 41dB NPR **
NPR 41dB Threshold
-57dBmV/Hz
**NOTE: As measured with 10dB of fiber and OTOR-300 High Sensitivity Return Band Receiver
OPTICAL PARAMETERS:
Wavelengths (OTPT-347 thru 361)
1470, 1490, 1510, 1530, 1550, 1570, 1590 or 1610 nm ±3 nm
Laser Type; Optical Output Power (OTPT-347 thru 361)
Course Wave Division Mux: +2.0mW ±0.5mW
Specifications
OTPN-2000C / OTPT-300A
High Output FTTP Premise Node Optical Receiver with Optional Return Transmitter
