Specifications
OTEA-CM Series
LaserLite: 1550nm EDFA
Ordering Information:
Model Number Description
Model OTEA-CM-B-nyy-SA-pp EDFA, 2RU Booster, 8-20 outputs, for use with Direct Mod 1550nm
transmitters, shuttered SC/APC optical connector
Where
n
Number of outputs: 8, 16, 18, or 20
yy Optical output per port (dBm) Valid options are 18, 20 & 21dBm.
pp Power: AC specifies universal AC input; DC specifies 48 Volts DC input
Min Typ Max Units
Wavelength 1550 1560 nm
Gain Flatness Over
λ Range
±3 dB
Noise Figure (@+6dBm In) 3.7 4.5 dB
Analog CNR Degradation 1 dB
CSO -63 -58 dBc
CTB -70 -65 dBc
Optical Input Range 0 +6 +10 dBm
Optical Output Power
(per port)*
+18 +21 dBm
*(per appropriate OTEA-CM Series Module)
Min Typ Max Units
Power Supply Voltage (Std) +85 +265 V
AC
Power Supply Voltage (Option) -36 -60 V
DC
Power Supply Frequency 47 63 Hz
Power Consumption (2RU Unit) 70 W
Operating Temp. Range -10 +50 °C
+14 +122 °F
Humidity (RH Non Con.) 15 85 %
Optical Characteristics (with SM 9/125μm Fiber) Electrical and Environmental Characteristics
Min Typ Max Units
Dimensions (W x H x D) 19 x 35 x 12.25 in
2RU (Unit) 483 x 88 x 311 mm
Characteristics
EDFA Interfaces
Optical Output Connector
Shuttered SC/APC
RS232 Control Interface DB-9, Commands, report alarms,
set alarm limits, and monitor
functions
LED Indicators SUPPLY, PWR IN, PUMP,
(Yellow/Red/Green) MODE, EQUIP, PWR OUT,
FANS (see manual for description)
Laser Enable/Disable Key switch (key cannot be
removed when in the ON position)
