RF INPUT CARD OPTIONS
ATSC Broadcast Input
(8701A)
Single Input Port, 8VSB and 64/256 QAM-B
DVB-S/S2 Satellite Input (8710A)
Dual Input Ports, DVB-S QPSK, DVB-S2 QPSK, 8PSK
ASM Receiver Card (8711)
Dual Input Ports (Turbo PSK, DVB-S PSK)
DVB-T/COFDM Broadcast Input (8715)
Dual Input Ports, QPSK, 17/64 QAM, 2K & 8K FFT Sizes
DVB-S/S2 Satellite Input with LNB Power (8716)
Quad Input Ports, DVB-S QPSK,DVB-S2 QPSK, 8PSK,
Multistream, VCM, 16/32APSK
SERIAL INPUT/OUTPUT CARD OPTIONS
ASI/SMPTE 310M Input and Output
(8702)
Selectable ASI or SMPTE 310M
IP INPUT/OUTPUT CARD OPTIONS
MPEG over IP Input/Output
(8725)
Transmits and Receives Multiple Streams Simultaneously,
Supports Pro-MPEG COP3 FEC, IGMPv2/v3, HRTP, and
Null-Stripped VBR
Dual MPEG over IP Input/Output (8727)
Transmits and Receives Multiple Streams Simultaneously,
Supports Pro-MPEG COP3 FEC, IGMPv2/v3, HRTP, and
Null-Stripped VBR
CONDITIONAL ACCESS OPTION
DVB Common Interface and BISS Descrambling Option
(8721)
Dual DVB-CI CAM Slots, Multiple Program Descrambling,
Support for All Major CAMs and Encryption Systems, BISS 1 & E
GENERAL PURPOSE CARD OPTIONS
GPIO Module Card
(8713)
VIDEO/AUDIO OUTPUT CARD OPTIONS
Analog Video Output
(8706A)
Component or Composite Video Outputs, Configurable
Component/RGBHV Output
Discrete Analog and Digital Audio Outputs (8707A)
Simultaneous Analog and AES Audio Outputs, Supports Two
Stereo Pair on both Analog and Digital Outputs
HD/SD-SDI, Component/Composite Video Output (8708)
Two user selectable serial digital (SMPTE 259M, or SMPTE
292M) outputs and one component RGBHV or YPbPr/Composite
NTSC & PAL output.
HD/SD-SDI, Component/Composite Video Output (8712)
Two user selectable serial digital (SMPTE 259M, or SMPTE
292M) outputs and one component RGBHV or YPbPr/Composite
NTSC and PAL output. Can provide simultaneous HD & SD/SDI
(must be used with the 8733)
DECODER CARD OPTIONS
MPEG2/MPEG4 4:2:0 SD/HD Decoder
(8732)
Single Video Program Decoder MPEG2/MPEG4, Two Audio
Services Decoding/Downmix/Pass-through
MPEG2 4:2:0 SD/HD Decoder (8730A)
MPEG2 only version of 8732 decoder
MPEG2/MPEG4 4:2:0 SD/HD Genlock Decoder (8734)
Single Video Program Decoder MPEG2/MPEG4, Two Audio
Services Decoding/Downmix/Pass-through, Genlock Black-and-
Burst or Tri-Level Sync
MPEG2 4:2:0 SD/HD Genlock Decoder (8731A)
MPEG2 only version of the 8734 decoder
MPEG2 4:2:0/4:2:2 SD/HD Genlock Decoder (8733)
Simultaneous HD and Down-converted SD Outputs, Single Video
Program Decode, Four Audio Services Decoding/Downmix/Pass-
through, Genlock Black-and-Burst or Tri-Level Sync
Specifications
MRD 3187B
Modular Receiver Decoder
The MRD 3187B receiver decoder solutions provide operators
a choice of I/O options required today, and the flexibility to
easily change in the future. The modular design of the MRD
3187B allows the operator to customize a compact, modular
chassis with a variety of input and output modules.
Multi-Standard Video Decoding Support
The MRD 3187B is capable of decoding all MPEG2 and H.264
Transport Streams from Main Profile through High Level,
including 4:2:0 and 4:2:2. Analog options include: NTSC/PAL
and RGB/YPbPr. Digital video options include HD/SD-SDI.
Multi-Standard Audio Processing
The MRD 3187B has embedded, digital and anolog audio out-
puts. Wide variety of supported audio codecs including: MPEG
Audio, Dolby AC-3, Dolby-E, AAC and HE-AAC Audio. Audio
can also be embedded in HD/SD-SDI.
Not Just A Receiver Decoder
The MRD 3187B receiver decoder enables operators to gain
valuable information about the decoded video and audio sig-
nal. The video and audio bitrate, aspect ratio, native format,
and other useful information can be viewed to verify the quality
of the decoded signal.
Selected PSIP data can be decoded and viewed, allowing
quick verification of PSIP data presence, as well as verification
of the content of each PSIP table.
Complete Remote Operation
In addition to front panel control, the MRD provides remote
configuration and monitoring capabilities through SNMP as
well as the most intuitive web client in the industry. SNMP
management can be done through Ethernet or RS232.
