Specifications
AV Tools Captioning
Feature VSCC VCC
Type S-Video Closed Captioning Video Closed Captioning
Physical 5.5” [140mm] W x 1.1” [28mm] H x 3.5” [86mm] D
8 oz [226g]
All aluminum enclosure with durable black powder coat paint
Surface mount or in equpment rack, up to 3 units in optional RK3 Rack Mount
Front Panel BNC Video Out BNC Video Out
Mini-DIN S-Video Out
BNC Video In
BNC Video In
DIP Switch, 4 position DIP Switch, 4 position
Captive Screw Terminal Captive Screw Terminal
1 GND 1 GND
2 Captions 2 Captions
3 Unassigned 3 Unassigned
4 Video Detect 4 Unassigned
5 DC Power 5 DC Power
Power LED Power LED
DC Power In DC Power In
DIP Switch Sets Caption modes CC1-4, TT1-4
Sets control options, including momentary/latching
S-Video Out VSCC Only
Mini DIN 4-pin, Y - 1V p-p at 75 ohms, C - 0.286 V p-p at 75 ohms
Digital adaptive 2-D Y/C separation filtering,
cross-color and cross-luminance reduction
Differential Phase .3° max, Differential Gain .2% max
Video bandwidth 10MHz, Luma S/N 77dB
Maximum video output 1.5V p-p
Power 2.1mm coaxial jack, 100 mA max
11.5 to 16.5 VDC, 12 VDC typical, may be unregulated
Includes 12 VDC power supply, inside center conductor positive, 100 mA
(domestic shipments only)
Options RK3 Rack Mount, 1 RU, mounts three AV Tools across
