DV4
TM
Digital Signage System
The Video Messenger DV4 is powerful market-
ing and communications tool that lets you
schedule and display high impact video, images
and PowerPoint® presentations over local and
remote television screens. Our manager soft-
ware automatically scales raw images straight
out of your digital camera. The software even
automates the process of adding PowerPoint®
slides, turning them into Jpg images for presen-
tation.Display messages directly on your televi-
sion screens or integrate the DV4 into your
cable headend, satellite system or CCTV sys-
tem. Simply add your media, create a playlist
and export it to the DV4. Multiple DV4 units can
now be centrally controlled using VMC's Upload
Service. This service allows you to simply
upload your playlists and media to a server.
Your DV4 units will check in to the server on a
regular basis to automatically download any
new presentations.
Screen Media Standards Support
• Image: JPEG baseline, up to 12
megapixels, scaled for display at 1280 x
720
• Audio: MPEG L2 or MP3, up to 128 Kbps
• Video: MPEG-1 or MPEG-4 ASP (DivX),
up to 640x480 @ 2 Mbps
NOTE: MPEG 2 video is NOT supported
Digital Signage Features
• Auto-play starts playing scheduled con-
tents automatically when power is re-
established
• Automatic error recovery with built-in
WDT
• Real-time clock keeps time for accurate
scheduled playback
• Automatic NTP keeps time and date in
sync
• Screw-lock connectors for reliable instal-
lation
Playback Control
• W3C SMIL 3.0 instructions (sub-set)
• Real-time clock playlist events
• Network playlist sync
• USB direct sync
Content Management
• Manager Express
• VMC's internet Uploader Service
Display and Sound
• VGA and HDMI video output up to 1280
x 720 resolution
• NTSC/PAL composite video output at
480i
• Stereo audio output
Port Connections
• HDMI 1.2 (up to 720p with audio)
• D-SUB VGA connector
• 3.5mm combined analog A/V out jack
• RJ45 Ethernet Port
• USB host x1
Mounting Options
Integral 142.5mm x 75-100mm flange
Local Storage
• 2GB flash memory (approx. 120 minutes
of video @2Mbps or thousands of still
images)
• SD card slot (card replaces internal stor-
age)
Supplied Accessories
• 3.5mm to RCA x3 A/V cable
• Ethernet cable
Power
• AC adapter 12V 1.5A
• Power consumption: 5W typical
Environmental
• Operating temperature: 0 to 40°C
• Humidity: 5 to 85% @ 40°C,
non-condensing
Dimensions (WxHxD)
• 6.0" x 5.1" x 0.83" (151mm x 130mm x
21 mm)
Weight
• 0.89 lbs (0.404 kg)
Certifications
• CE / FCC / RoHS
Warranty
• 1-year limited parts & labor
Specifications
