Toner Cable 7820IG10-IP IntelliGain Processor for Compressed IPTV-ASI Signals - Manual (Page 2)

Specifications Subject To Change Without Notice Rev 1 -12 © Toner Cable Equipment, Inc.
,*,3
,QWHOOL*DLQ Š 3URFHVVRU
IRU&RPSUHVVHG,379$6,6LJQDOV
969 Horsham Road l Horsham, Pennsylvania 19044 USA l Phone: 215-675-2053 Fax: 215-675-7543 l [email protected]
Ordering Information
7820IG10-IP IntelliGain ® Processor for Compressed IPTV/ASI Signals
Ordering Options: Rear Plate must be specified at time of order
Eg. Model +3RU
+TSM Transport Stream Monitor
7700FC VistaLINK® Frame Cobntroller
CP-2116E-H Remote Control Panel
CP-2232E Remote Control Panel
Rear Plate Suffix
+3RU
3RU Rear Plate for use with 7800FR Multiframe
Enclosures
7800FR
3RU Multiframe which holds up to 15 single slot modules
7800FR-QT 3RU Multiframe which holds up to 15 single slot modules
7801FR 1RU Multiframe which holds up to 4 single or 2 dual slot modules
Specifications
Inputs & Outputs:
Number of Ethernet:
2 (control & data)
Standard: IEEE 802.3 (10 BaseT)
IEEE 802.3u (100 BaseTX)
IEEE 802.3ab (1000 BaseTX)
Connector: RJ45
Cable Requirements:
10 BaseT UTP Category 3, 4 or 5 up to 100m (2 pair)
100 BaseTX UTP Category 5 up to 100m (2 pair)
1000 BaseTX UTP Category 5 up to 50m (2 pair)
Electrical:
Voltage: +12V
DC
Power: 20W
EMI/RFI:
Complies with FCC Part 15
Class A EU EMC Directive
Physical (number of slots):
7800FR
2
7800FR-QT 2
