Cat6s series, Specifications – Toner Cable CAT6S Series Category 6 Patch Cords, 550 MHz Shielded Network Cable User Manual
Page 2
Specifications Subject To Change Without Notice
Rev 12-12
©Toner Cable Equipment, Inc.
969 Horsham Road
l
Horsham, Pennsylvania 19044 USA
l
Phone: 215-675-2053 Fax: 215-675-7543
l
Specifications
CAT6S Series
Category 6 Patch Cords, 550 MHz Shielded Network Cable
Applications
Telephony Voice Wiring, Network T Base 10 / 100 / 1000, Digital Video, IPTV, UL Subject 444, EIA / TIA568 & ISO / IEC
11801
Construction
Center Conductor
4 pairs 0.0226” (23 AWG) standed bare copper
Dielectric:
0.0403” PE
Separator Cross:
PE
Shield:
AL / PE laminated tape
Outer Jacket:
0.248” PVC
Connector:
RJ-45
Electrical Characteristics at 20°C
Conductor Resistance (Max):
98.6
Ω / km
Insulation Resistance (Min):
5000 M
Ω / km
Capacitance:
< pF / m
Impedance:
100
Ω (±15%)
Operating Temperature:
-20 to +65°C
• PVC - Polyvinylchloride • AWG - American Wire Gauge • AL / PE - Aluminum / Polyethylene
