SMP180
Multi-Channel Receiver
DVB-S/S2 Input
4XRF input per module (three modules in 1 RU)
Constellation
QPSK, 8 PSK
Symbol Rate
DVB-S
1~45 Msps
(QPSK: 1/2,2/3,3/4,5/6,7/8)
DVB-S2 1~31.5 Msps
(QPSK: 1/2,3/5,2/3,3/4,5/6,8/9,9/10;
8PSK: 3/5,2/3,3/4,5/6,8/9,9/10 )
Input Frequency 950~2150 MHz
Signal Level ~-65~-25 dBm
Acquisition Range +/- 5 MHz
Tuner Step Size 100 KHz
Return Loss >10 dB
LNB Power
Vertical
11.5V~14.0V,
Horizontal 16.0V~19.0V, 22kHz/off
22K Switch on/off
QAM RF Input (optional)
Input Frequency Range
48 -862 MHz
RF Channel 4 (6/7/8 MHz) per module
QAM Modulation Mode 16/32/64/128/256 QAM
QAM Type ITU-T J.83 Annex A/ C, Annex B
(Future feature)
Symbol Rate 1.0~6.9 MBauds
RF input bit-rate up to 55 Mbps
DVB De-scrambling
DVB-CI Interfaces
up to 4 independent CI slots
(EN50221)
CA Method Multicrypt/Simulcrypt, Hot Plug
CAS Irdeto, Conax, Viacess, Nagravision,
Novel SuperTV, Verimatrix, CTI,
Dvcrypt&other DVB-simulcrypt CAS
GBE IP Interface
Interface 1 x 1000 Mbps per port
IP Encapsulation MPEG TS over UDP/RTP
MPEG TS MPTS and SPTS
I/O Processing Up to 12 Sockets,
max at 72 Mbps per socket
Addressing Unicast and Multicast
Management IGMPv1, IGMPv2, IGMPv3
Forward Error Correction ProMPEG
DVB ASI Interface
Interface
4 BNC connectors
(2 ASI inputs and 2ASI outputs), 75Ω
MPEG Format 188/204Bytes per TS
I/O Processing 1 MPTS/SPTS per port, up to
120 Mbps per port
Re-multiplexing
PID
Re-mapping and Filtering
MPTS Output Synchronization
Routing
Any Input to Any Output
Redundancy Input Service Redundancy & IP Port
Redundancy
Management
Interface
100BaseTX, RJ45
NMS Wellav Digital Service Manager
Web-based Management (future feature)
Support SNMP
Physical & Environment
Input Voltage
90 – 260 VAC
Power Consumption Approx 60 W
Rack Space 1 RU
Dimension (WxHxD) 19 x 1.75 x 17.3”
480 x 44 x 440mm
Operating Temperature 0 to 50°C
Storage Temperature -40 to 65°C
Relative Operating Humidity <95%
Order Information
SRS2
DVB-S2 Receiver (12 channel)
SRSCI DVB-S2 Receiver (4 channel w/ 4 CI)
SRC DVB-C Receiver (12 channel)
SRCCI DVB-C Receiver (4 channel w/ 4 CI)
