CARK Series Specifications
Rack-Mountable Push-Pull Headend Amplifier
 ±0.5 dB flatness across band provides low distortion and excellent frequen-
cy response
 Front panel controls and test point enable easy setup and monitoring
 Built-in lightning and line voltage surge protection protects the unit from
damage
 Low noise performance, eliminating addition of offending picture static
MODEL CA-30RK1000 CA-30RK550 CA-45RK550
Bandwidth: 54-1000 MHz 54-550 MHz 54-550 MHz
Gain: 30 dB 30 dB 45 dB
Maximum Output: 60 dBmV 60 dBmV 58 dBmV
Flatness: 0.5 dB
Composite Second Order: 70 dB
Composite Triple Beat: 61 dB
Output Return Loss: 15 dB
Output Test Point Loss: 30 dB
Voltage Input: 115 VAC
Power Frequency: 60 Hz
Power Required: 4 Watt
Dimensions: 19”L x 3”D x 1.75”H
Weight: 3.8 lbs
CA Series Specifications
Stand-Alone Push-Pull Distribution Amplifier
 Employs state-of-the-art hybrid push-pull technology for distortion-free
audio-video quality
 Adjustable slope and gain controls for easy system balancing
 Easy-access controls and low-loss (-20 dB) test point enable simplified
setup and performance monitoring
 Built-in lightning and line voltage surge protection protects the unit from
damage
MODEL CA-30/1000 CA-30/550 CA-50/550
Bandwidth: 54-1000 MHz 54-550 MHz 54-550 MHz
Gain: 30 dB 30 dB 50 dB
Maximum Output (36 ch): 38 dBmV 53 dBmV 53 dBmV
Flatness: 0.5 dB 0.5 dB 0.5 dB
Noise Figure: 5 dB 4.5 dB 6 dB
Composite Second Order: 60 dB 70 dB 60 dB
Composite Triple Beat: 58 dB 61 dB 58 dB
Input Test Point Loss: 20 dB
Output Test Point Loss: 20 dB
Voltage Input: 115 VAC
Power Frequency: 60 Hz
Power Required: 4 Watt
Dimensions: 8”L x 2.75”D x 4.5”H
Weight: 2.5 lbs
